Blackmagic Videohub Mini 6×2 12G

Overview
Blackmagic Videohub Mini 6×2 12G is a compact video router supporting SD, HD, and Ultra HD formats simultaneously. It features 6 12G-SDI inputs, 2 outputs, reference connections, and a front panel control panel for quick routing. The router eliminates cable mess and is ideal for adding extra inputs to various broadcast equipment, making changes without rewiring racks.

Blackmagic Videohub Mini models include 4×2, 6×2, and 8×4 12G options, with advanced 12G-SDI connections supporting multiple video formats. The front panel design allows for fast switching and video patching, with each output having its own clean switch function. Additionally, all models feature SDI re-clocking on every input for optimal video quality and error prevention.

Included in box
1x Blackmagic Videohub Mini 6×2 12G

1x Welcome wallet with QR code for software download

About the Blackmagic Videohub Mini 6×2 12G
Blackmagic Videohub Mini

Blackmagic Videohub Mini 6×2 12G is a compact zero latency video router that supports any combination of SD, HD and Ultra HD on the router at the same time. It has 6 12G-SDI inputs and 2 12G-SDI outputs plus reference connections for locking clean switch outputs in a compact 1/2 rack width size. The front panel control panel lets you quickly route a video connection and even includes an emergency 12G-SDI connection for patching in external gear and USB-C webcam video out. It also features SDI re-clocking, external Ethernet control and supports all SDI video standards up to 2160p60.

Eliminates Complex Cable Mess

Blackmagic Videohub Mini routers are designed for adding extra inputs to all types of SDI broadcast equipment. They are designed to be small, so they take up very little space in mobile racks, where space is limited. You can add extra inputs to ATEM switchers, or add input selection to streaming encoders and HyperDeck recorders. You can also use it to add extra inputs to video monitors! Routers are fantastic because you can make changes to connections without frantically patching cables in the middle of a job. If you have an urgent customer need or emergency, you can connect gear to the SDI connections on the front panel. That means you can handle the unexpected without rewiring your rack.

Blackmagic Videohub Mini 4×2 12G

Tiny SD, HD and Ultra HD video router has 4 x 12G-SDI inputs with a loop output for each input as well as 2 dedicated 12G-SDI outputs. It includes a front panel router control panel that also has an emergency 12G-SDI input and USB-C webcam video out!

Blackmagic Videohub Mini 6×2 12G

This model is ½ rack width and features 6 x 12G-SDI inputs with loop out, 2 x 12G-SDI outputs and reference for locking clean switch outputs. The front panel has router control as well as a 12G-SDI input, 12G-SDI output and USB-C webcam connections.

Blackmagic Videohub Mini 8×4 12G

The largest model is ⅔ rack width and features 8 x 12G-SDI inputs with loop outputs, 4 x 12G-SDI outputs and reference input for the clean switch. The front panel has router control plus a 12G-SDI input, 12G-SDI output and USB-C webcam connections.

Front Panel Includes Router Control and Video Patching

The front panel design of the Blackmagic Videohub Mini has been designed for fast cut-bus style switching with dedicated buttons for outputs and inputs. To route a video connection, simply select the destination button and then press the source button! That provides all the routing control you need, even though the routers are designed to fit into small, portable racks. The front panel also has 12G-SDI video connections for patching in external gear, and the front panel input connection will override the highest rear input connection when video is connected. The front panel also has a USB webcam output so you can connect a computer for recording, video scopes or streaming software.

Advanced 12G-SDI for SD, HD and Ultra HD Routing

All models of Blackmagic Videohub Mini feature advanced 12G-SDI connections which are multi rate so they support any SD, HD and Ultra HD video format up to 2160p60. That means you can connect any SD, HD-SDI, 3G-SDI, 6G-SDI and 12G-SDI equipment. Plus Blackmagic Videohub Mini also supports routing any video standard on the same router at the same time. 12G-SDI gives you high frame rate Ultra HD via a single BNC connection that also works with all your regular HD equipment, so you can seamlessly switch different video inputs and the SDI output standard will change automatically! With 12G-SDI you get a future proof technology that connects to the equipment you have now and in the future!

Each Video Output Has Its Own Clean Switch!

All models of the Blackmagic Videohub Mini feature a “clean switch” function that ensures stable video transitions when switching between sources. However, the clean switch feature is unique because it’s set on each output, not on the inputs. This is important because the re-sync processors needed for clean switch can add or remove video frames from the video. So this means you could set a HyperDeck recorder to a non-clean switch direct feed because you don’t want extra frames inserted, while a monitor or streaming encoder router output could use the clean switch, ensuring seamless source changes. The clean switch will lock sources to input 1 or the reference input on the 6×2 and 8×4 models.

Features Full SDI Re‑Clocking

All models of Blackmagic Videohub Mini feature built-in SDI re‑clocking on every 12G-SDI input. SDI re-clocking regenerates the video signal to ensure optimal video quality and prevent SDI data errors. This is extremely important because longer video cables degrade the signal. Expensive premium “digital” cables can provide some assistance, but they are still unable to completely eliminate signal integrity loss caused by the increasing length of cables. By re-clocking all the SDI devices in your studio, all your equipment will receive a regenerated signal with enhanced jitter performance. That means you get longer cable lengths and the absence of video dropouts.

Includes Front Panel Emergency Patch Connections

Blackmagic Videohub Mini features incredibly useful 12G-SDI patch connectors on the front panel for direct video access. This means you don’t have to fumble around in the back of a rack with cables, so you won’t accidentally unplug something crucial! That’s great when you need to add external extra gear in an emergency. Or you have an unexpected client need! All models have a front panel 12G-SDI input that overrides the highest rear video input when connected. The 6×2 and 8×4 models also feature a front panel 12G-SDI output that’s the same video as the highest output number. Using the highest inputs and outputs is preferred as they are the least likely used connections on any video router!

USB Webcam Output for Computer Video

You can live stream directly from the router’s front panel because the front USB-C connection functions as an HD webcam video source. You can plug into a computer and work with any video software! The software is tricked into thinking the router is a common webcam, but it’s really an SDI video source! You get full compatibility with any video software in full resolution 1080HD quality. If your video source is Ultra HD, then it will be down converted to HD for the webcam output. You can route live SDI video into common video software like Zoom, Microsoft Teams or Skype for broadcast quality presentations! Or use streaming software such as Open Broadcaster, XSplit Broadcaster and more!

Add External Hardware Control Panels

All Blackmagic Videohub routers can be remotely controlled, which is vital in large broadcast studios where the equipment connected to the router is located in different areas of the building. There are 2 different types of hardware panels available. The Videohub Master Control Pro is similar to the front panel and has a spin knob, LCD and shortcut buttons. While the Videohub Smart Control Pro model features all buttons and is generally programmed so the panel controls a single router output with each button programmed to a router input. Then you can just cut along the panel buttons to change the router output instantly. It works best when you install a smart panel below each video monitor!

Get Router Control on Mac, Windows and iPad

If you need to remotely control a Blackmagic Videohub Mini, then Videohub Software Control is an ideal solution because it’s free to download. Videohub Software Control is compatible with both Mac and Windows, allowing you to run it on the computers you already use for creative work. The software has large, easy-to-press icon style buttons. Each button can be customized to either a router input or a router output, and you can also assign each button a custom icon to aid visual identification. The big buttons are great for use on a touchscreen PC, where the software becomes a large screen XY control panel! You can even download a version of the software for the Apple iPad!

Includes Videohub Setup Utility

Since the Videohub Mini has front panel routing buttons, you don’t require any setup before using it. However, if you want to remotely control the router, you can use the free Blackmagic Videohub Utility to customize the input and output labels. This enables the use of external control panels. Blackmagic Videohub Setup is incredibly useful as it provides access to all advanced router features. Use the software to create remote labels for front panel buttons, update router software, set Ethernet settings and configure external hardware panels. You can download the software free of charge from our website. It supports both Mac and Windows operating systems and connects via Ethernet or USB.

Supports Multiple Formats

When you need to work on global events, then you need to stay updated with the latest technology and television standards. Videohub gives you support for all 525 NTSC, 625 PAL, 720p, 1080i, 1080p, 2K, 4K and all Ultra HD video standards. Plus you can connect multiple video standards simultaneously!

Embedded Audio for Audio and Video

The SDI standard includes up to 64 channels of embedded audio with the 12G-SDI video signal. The advantage of embedded audio is that it all connects with a single BNC cable, and all audio remains perfectly synchronized to the video. Plus all modern SDI equipment supports embedded SDI audio!

Embedded Audio for Audio and Video Deeper Bit Depth and Color Precision

Videohub is designed to support the highest quality video. 10-bit is the most commonly used standard as colors can be represented more accurately than 8-bit video. You can route 4:2:2 8-bit or 10-bit video in any standard, and it even works with 4:4:4 12-bit SDI up to 2160p30 for feature film!

Localized for 13 Popular Languages

Blackmagic Videohub routers support internal labels in Unicode, so when you use external software control you can customize the labels to the language you prefer. Plus, the software utility for router settings has been localized to English, Chinese, Japanese, Korean, Spanish, German, French, Russian, Italian, Portuguese, Turkish, Polish and Ukrainian. However, independent of the language you have set on your local computer, the labels are completely independent and are always Unicode, so you could even customize the labels to be a mix of multiple languages if required! Multiple languages means you can work anywhere in the world and with any local crew!

Custom Router Control with the Developer SDK

All Videohub models come with a free software development kit, making it simple for developers and system integrators to add protocol support and quickly integrate into broadcast automation systems. Plus all Videohub routers use a simple text based protocol that’s easy to learn. It simplifies creating custom control solutions for various computer platforms and embedded hardware like Raspberry Pi and Arduino. The protocol can even be used with a Telnet app so you can experiment with controlling the router before you start coding! The protocol is the same one used for the Videohub Software Control, which is well-tested and includes all the features required for complex control applications.

Includes Front Panel Emergency Patch Connections Flexible and Redundant Power

The Blackmagic Videohub Mini routers include a built in AC power supply. This lets you plug into any regular wall outlet with a standard IEC power cable. The international power supply operates automatically between 100 and 240 volts AC, ensuring that you can continue using your equipment while traveling across different regions globally. Although the Blackmagic Videohub Mini supports AC power, it also features a 12V DC power connection. This dual power option allows for redundancy and can be used when you do critical work that requires the router to stay operating in case of a PSU fault or power outage.

SDI Video Inputs 6
Front panel input overrides rear input 6
SDI Video Outputs 2
Front panel output mirrors rear output 2
SDI Rates 270Mb, 1.5G, 3G, 6G, 12G.
Video Input Re-Sync On all 6 inputs for clean switch.
SDI Reclocking On all SDI outputs.
Reference Inputs Tri-Sync or Black Burst.
Reference Outputs Reference terminating loop output.
Webcam Output USB‑C
Ethernet Supports 10/100/1000 BASE‑T.
Computer Interface 1 x USB Type‑C 3.1 Gen 1 for webcam out, software updates and Videohub Setup Utility connection.
SD Video Standards 525i59.94 NTSC, 625i50 PAL
HD Video Standards 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
2K Video Standards 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI
Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60
4K Video Standards 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI
SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-10, ITU‑R BT.656 and ITU‑R BT.601
SDI Audio Sampling Television standard sample rate of 48kHz and 24‑bit.
SDI Video Sampling YUV 4:2:2 and RGB 4:4:4
SDI Color Precision 10, 12‑bit RGB 4:4:4 in all HD and 2K modes, Ultra HD modes up to 2160p30 and 4K modes up to 4Kp30 DCI. 10-bit YUV 4:2:2 in all modes.
SDI Color Space REC 601, REC 709, REC 2020
SDI Auto Switching Automatically selects between 270Mb SD‑SDI, 1.5G HD‑SDI, 3G level A and level B HD-SDI, 6G HD‑SDI and 12G‑SDI on each input so that each input can be running a different television standard.
SDI Metadata Support Video payload identification ancillary data as per SMPTE 352M.
