Swit LB-SU90C BP-U-type DV Battery

Overview
The LB-SU90C is a 90Wh SONY BP-U battery that is compatible with a variety of cameras, including the SONY PXW FS5/FS7, PXW-FX6/FX9, and PXW-Z280/X280. With a 14.4V nominal voltage and 90Wh/6200mAh capacity, this battery can power cameras for extended periods of time. It also features a built-in 14.4V D-tap output and charging input, as well as a 45W USB-C input and output. The battery also has a 4-level LED power indicator and multiple circuit protections to ensure safe and reliable use.

The LB-SU90C is equipped with a D-tap power socket that provides a high load of 70W/6A for various video devices. It can also be charged via the D-tap socket using a SWIT PC-U130B2 charger. Additionally, the battery has a USB-C socket that can output 45W of power for laptops, tablets, and smartphones. It can also be charged by a USB-C charger, with a 45W power input that allows for a full charge in just 3 hours. The battery also has a 4-level power indicator and can be charged using a variety of chargers, including the SWIT S-3602U 2-way charger, PC-U130B2 D-tap charger, and LC-D421 4-way charger.

Summary
Battery Capacity: 90Wh
Battery Capacity: 50-98Wh
Battery Indicator: Yes
Battery Mount / Type: Sony BP-U
Battery Technology: Li-ion
Voltage: 14.4v
Included in box
1x Swit (LB-SU90C) 90Wh BP-U-type DV Battery with USB-C and D-tap

About the Swit LB-SU90C BP-U-type DV Battery
90Wh SONY BP-U Battery with D-tap and USB-C
LB-SU90C is a new 90Wh large capacity BP-U type DV battery with D-tap output and 45W USB-C in/out, for SONY PXW FS5/FS7, PXW-FX6/FX9, PXW-Z280/X280 etc.

90Wh Large Capacity
LB-SU90C consists of 8pcs battery cells, 14.4V nominal voltage, 90Wh/6200mAh large capacity to keep cameras powered for longer time. The constant power load is 70W/6A.

14.4V D-tap Power Socket
The LB-SU90C BP-U battery provides a D-tap power socket of 11-16.8V voltage, 70W/6A high load for various kinds of video devices. You can also charge the battery via the D-tap socket by SWIT PC-U130B2.

USB-C 45W for Laptop
LB-SU90C provides a USB-C socket of 5V/9V/12V/15V/20V(Max) 2.25A, 45W power output for various kinds of laptop, tablets or smart phones, supports BC1.2, PD2.0/3.0, QC2.0/3.0, FCP, SCP multiple protocols.

(For Macbook 13, Macbook Pro 13/15, ThinkPad New S2/T470/X270, Dell XPS 13/Latitude, HP Spectre x360-13/EliteBook Folio G1, Samsung Chromebook Plus, Google Pixelbook, Huawei Matebook, etc)

USB-C 45W Charging Input
You can also charge LB-SU90C by USB-C charger. Supports 5V/9V/12V/15V/20V(Max) 2.25A, 45W power input, which means you can fully charge the 90Wh battery within 3 hours.

4-level Power Indicator
Press the power check bottom, the 4-level LEDs indicates remaining power percentage.

4-way Charging
LB-SU90C can be charged by SWIT S-3602U 2-way charger, SWIT PC-U130B2 D-tap charger, or LC-D421 4-way charger. By the LC-D421, You can charge 4 batteries simultaneously, and fully charging within 3.5 hours.

Nominal Voltage 14.4V
Capacity 90Wh, 6.2Ah
Max power load 70W, 6A
D-tap 14.4V, 70W, 6A
USB-C
45W input 5V/9V/12V/15V/20V, 2.25A
45W output 5V/9V/12V/15V/20V, 2.25A
BC1.2, QC2.0/3.0, PD2.0/3.0, FCP, SCP
Original batteries SONY BP-U30, BP-U60, BP-U100
Compatible cameras SONY PXW-FS5/FS7, PXW FX6/FX9, PXW-Z280/X280 etc
Dimension 70×42×96mm
Charging Temperature 0-40°C
Discharging Temperature -20°C-50°C (Capacity and Max Load may decrease when operating below 0°)
Net weight Approx 462g

14.4V nominal voltage Li-ion battery
Compatible with SONY BP-U batteries
Display remaining power info in camera
90Wh / 6.2Ah capacity
Built-in 14.4V D-tap output / Charging input
Built-in 45W USB-C input and output
4-level LED power indicator
Multiple circuit protections
