Sony GN60 External Flash

OVERVIEW
The Sony HVL-F60RM2 (HVLF60RM2) External Flash with Wireless Radio Control is a must-have for any photographer looking to elevate their creative photography. This versatile flash offers improved algorithms and stable light emission, allowing for great wireless flash performance. With its high GN60 output, this flash is perfect for wedding photography, portrait flash, and more.

One of the standout features of the HVL-F60RM2 is its intelligent communication with Sonys genuine high power flash system. This allows for reliable and precise light control, ensuring consistent GN60 light output at every flash. It also supports focal lengths from 20mm to 200mm, making it suitable for a wide range of applications.

The flash also boasts a fast recycle time and dependable high-speed continuous shooting, allowing for up to 200 consecutive flashes at 10 frames per second. This is made possible by advanced electronics and construction, as well as the option to use the FA-EBA1 external flash battery adapter for even faster recycle times.

Thanks to its comprehensive control from compatible cameras, the HVL-F60RM2 offers intuitive operation and quick shift bounce, making it easy to capture key moments in portrait photography and as a wedding flash. The flash also features versatile radio wireless communication, allowing for various shooting styles.

Not only is the HVL-F60RM2 a powerful and versatile flash, but it is also built to last. Its metal shoe foot with rugged side frame significantly increases its strength and durability, while enhanced dust and moisture resistance ensure it can withstand even the toughest shooting conditions.

In summary, the Sony HVL-F60RM2 is the perfect flash for professionals and enthusiasts alike. With its intelligent communication, stable high-power output, fast recycle time, and comprehensive control, this flash is a fantastic addition to any photographers toolkit.

INCLUDED IN BOX
External Flash wih Wireless Radio Control
Connector protect cap
Mini-stand
Case
Bounce adaptor
Colour filter (amber)
Colour filter (green)
Carrying pouch

About The Sony GN60 External Flash
Introducing the Sony HVL-F60RM2, a versatile, high power flash for creative photography. Improved algorithms and stable light emission in conjunction with the camera body offer great wireless flash performance. Enjoy easy operability with this radio controlled flash, enabling various shooting styles, and a stable, consistent high GN60 output. Up to 200 consecutive flashes at 10 frames per second is possible with this Sony flash.

GN60 High-output flash supports the latest camera technology
This durable high-output GN60 flash unit delivers levels of sophistication and camera communication that only Sony can offer, achieving reliable flash at high continuous shooting speeds and sync at shutter speeds up to 1/400 sec. Intuitive operation via the camera interface, quick shift bounce, and wireless radio communication add refined control and versatility.

Intelligent communication with the latest α bodies
α Lighting System has evolved in parallel with α camera bodies to give creators optimum illumination in a wide range of applications. A level of integration that is only possible with original Sony products achieves detailed communication with compatible camera bodies for reliable and precise light control.[1] Flash processor [2] Multi Interface Shoe [3] Image sensor [4] Image processor.

Stable high-power GN60 output that satisfies professional needs
Because the HVL-F60RM2 is designed and manufactured by Sony, it can communicate with α camera bodies to deliver consistent GN60 light output at every flash. The HVL-F60RM2 supports focal lengths from 20mm (14mm with the wide panel) to 200mm.

Backlit portrait of a man taken with flash in front of sunset
Flash control linked to camera face detection With a compatible camera, white balance is automatically adjusted so that the subject’s face is rendered with natural color. The HVL-F60RM2 works with a compatible camera3 face detection to provide ideal lighting for the main subject, even in groups.

Auto white balance accuracy that only original equipment can achieve
Thanks to in-house design, this advanced flash unit transfers colour temperature data to the camera where that data is used to precisely adjust white balance so that colours are rendered naturally in any situation.

Flash illumination angle is automatically adjusted to match the focal length of the lens used over a 20-200mm range. Light distribution is also adjusted for optimum illumination with full-frame or APS-C format.

Fast recycle and dependable high-speed continuous flash
Advanced electronics and construction contribute to fast recycle times and allow continuous flash shooting for extended periods of time. A set of four batteries can provide power for more than 240 flashes with 1.7 second recycle time4. The optional FA-EBA1 external flash battery adapter can be used to provide recycle times as fast as 0.6 seconds4.

Innovative overheating prevention for longer shooting sessions
The use of heat resistant materials plus an optimised flash algorithm provides higher resistance to overheating that allows longer flash shooting sessions.

Stable high-speed continuous flash shooting
With a compatible camera the HVL-F60RM2 can continuously provide flash for up to 200 frames in high-speed bursts at up to 10 fps. Missed frames dues to flash sync failure are avoided, providing stable continuous shooting support.

Up to 20 flashes per second
With the electronic shutter on a compatible camera, up to approx. 20 flashes per second can be produced continuously for more than 1 second. The FA-EBA1 external flash battery allows approx. 20 flashes per second for more than 10 seconds.

Up to 1/400 sec. shutter sync with a compatible camera for new expression
Used with a compatible camera body the HVL-F60RM2 allows flash sync up to 1/400 sec. This makes it possible to deemphasise the background while using flash to illuminate the main subject, illuminate moving subjects against a bright background, and more.

Per-frame P-TTL flash control adapts to changing light
When used with a compatible camera, high-speed control sequencing in the camera uses pre-flash to control each individual flash7 during continuous bursts, even when tracking fast-moving subjects in scenes where the light changes dramatically.

Fast angle adjustment with Quick Shift Bounce
Quickly angle the flash head 90 degrees to the left or right, 150 degrees up, or 8 degrees down, and rapidly switch between horizontal and vertical orientation. A revised mechanism is more compact and convenient.

Fast, intuitive direct light level controls
Dedicated + and – LEVEL buttons allow direct, speedy light output and flash compensation control, and can also be used to control the same parameters on other wirelessly paired flash units for smooth, efficient workflow.

Efficient TTL light level memory
TTL flash level can be memorised and later recalled for manual adjustment. This can greatly reduce the time required to manually set up flash parameters in a wide range of situations.

Versatile radio wireless communication
Stable wireless radio communication is ensured at distances up to 30 m/98.4 ft. Reliable, error-free communication is achieved even around reflectors and obstacles. Slow sync, rear-curtain sync, and multi flash are supported.

Wireless radio control for up to 15 flash units
Control up to 15 flash and/or receiver units in 5 groups. The HVL-F60RM2 can communicate with flash units that do not feature wireless radio communication via the optional FA-WRC1M commander and/or FA-WRR1 receiver.[1] Commander Function [2] Receiver Function

Auto AWB with colour filters
When one of the supplied colour filters is attached to the flash unit, the camera’s white balance is automatically adjusted for a natural mix between flash and ambient light.

Flash control with bounce adaptor
When the supplied bounce adaptor is used the flash unit communicates with the camera to achieve optimum flash distribution for soft, even lighting. The wide panel enhances this effect.

Wired IN/OUT sync terminal
A single sync terminal provides in and out sync connections. IN can be used to receive trigger signals from a flash meter, while OUT can be used to trigger additional flash units.

Type Auto electronic flash (clip-on type) with pre-flash metering
Shoe type Multi Interface Shoe.
Maximum Guide number 60 (Flash coverage setting 200 mm/STD flash distribution,ISO100・m)
Flash coverage AUTO/MANUAL(20 mm-200 mm)Angle of view at 14 mm focal length is also covered with the wide panel
Flash mode TTL/MANUAL/MULTI
Flash duration (Approx.) Within 2.8 ms(1/1 MANUAL)
Colour temperature (Approx.) 5500 K
Recycle time (Approx.)*1 0.1-2.5 seconds(Alkaline battery)/0.1-1.7 seconds(Ni-MH battery)
Number of flashes (Approx.)*2 More than 160 times(Alkaline battery)/More than 240 times(Ni-MH battery)
Continuous flash performance 200 flashes at 10 flashes per second *3
Bounce flash Yes
Bounce angle Up 150deg (0deg/30deg/45deg/60deg/75deg/90deg/120deg/150deg) Down 8deg
Left and right 90deg (0deg/30deg/45deg/60deg/90deg)
Test flash Yes
Flash control Flash control using pre-flash (P-TTL/ADI)
Flash compensation Yes *4
Power Level switching 25 levels(1/1-1/256) 1/3 steps
High-speed sync (HSS) Yes
Modeling flash Yes
Built-in wide panel Yes(14 mm)
Built-in bounce sheet Yes
Radio control wireless function:
Radio control wireless flash Yes(commander/receiver) *5
Frequencies 2.4 GHz band
Channels 14 Channels(Auto/manual)
Communication distance (Approx.)*6 30 m *7
Groups 3 groups(TTL/MANUAL),5 groups(group flash photography)
Maximum Flash units 15 units
Lighting ratio control 3 groups(TTL)
Other:
Auto zoom control optimized for image sensor size Yes *8
Flash distribution setting Yes
Auto WB adjustment Yes *8
Custom key settings Yes
Memory settings Yes
Remote release Yes
Display LCD panel: Yes(Dot matrix)
External connectors Sync terminal: Yes(IN/OUT)
External connectors: Multi/Micro USB terminal Yes
Power source Four AA-size alkaline or Ni-MH batteries
External Battery Adaptor YES
Dimension (Approx.) W 78.1 mm X H 143.1 mm X D 104.6 mm (3 1/8 inches × 5 3/4 inches × 4 1/8inches)
Weight (Approx.) 439 g (15.5 oz) (only main unit)
Material PC+ABS
Colour Black
Operating Temperature 0℃ to +40℃ (32°F to 104°F)
Storage Temperature -20℃ to 55℃ (-4°F to 131°F)
Dust and moisture resistant design*9 Yes
Notes *1 The recycle time is the fastest time from when the flash is emitted until the TEST button lights up.(Sony test conditions)
*2 The number of flashes is the number of times that maximum light output can be emitted once in 30 sec.(Sony test conditions)
*3 Normal flash, power level 1/32, 105mm, Ni-MH battery.
*4 Depending on the camera,this function is not available.For details,see product information page.
https://support.d-imaging.sony.co.jp/www/cscs/accessories/
*5 Requires Radio Control Wireless Flash(sold separately) or Wireless Radio Receiver FA-WRR1(sold separately) or
Wireless Radio Commander FA-WRC1M(sold separately).
*6 May vary according to conditions.
*7 SONY test conditions
*8 Except DSLR-A100.
*9 Not guaranteed to be 100% dust and moisture proof.
*10 Warranty and Operating Instruction are excluded.

Intelligent communication with Sony’s genuine high power flash system
Stable high-power GN60 output satisfies professional needs, making this a fantastic flash for wedding photography, portrait flash, and more
Fast recycle and dependable high-speed continuous Sony flash
Comprehensive control from compatible cameras
Versatile radio wireless communication
Fast angle adjustment with Quick Shift Bounce, helping you capture key moments when using the HVL-F60RM2 flash for portrait photography, as a wedding flash, and more
Minimal flash trigger time lag
Comprehensive control from compatible cameras
Metal shoe foot with rugged side frame significantly increases the strength and durability of the Multi Interface Shoe and its electrical contacts
Enhanced dust and moisture resistance
