SmallHD Oled 27 Monitor

OVERVIEW
SmallHD’s OLED 27 is their most advanced 4K OLED reference monitor to date. It boasts a remarkable combination of top-notch color accuracy and lightweight, portable design that is perfect for any workflow. With a brightness of up to 550nits and a contrast ratio of 1,000,000:1, this monitor allows for on-set previewing of HDR content. It also offers 10-bit color accuracy with 110% DCI-P3 and 135% Rec. 709 color gamuts for precise grading in post-production. The OLED 27 is compatible with Bolt 4K and comes with PageOS, a powerful software toolset designed for simplicity and speed up to 4K resolution. This includes features such as Waveform, Vectorscope, Color Pipe HDR color-rendering, and a Monitor Calibration Wizard.

The OLED 27 also features a Small4K Video Processing Architecture with 4x 12G-SDI inputs and 1x HDMI 2.0 input, as well as 4x 12G-SDI outputs and 1x HDMI 2.0 output. The PageOS software platform offers 4K HDR waveform and scopes, Multi-View, simplified HDR Color Pipe setup, and a Monitor Calibration Wizard. The monitor is powered by hot-swappable dual inputs, a 3-pin XLR, and a dual GM/VM battery plate (sold separately). Its unibody smart chassis includes a dovetail mounting rail for battery and accessory mounting, 2x 2-pin accessory power outputs, and interchangeable mounting points. Whether on location or in post-production, the OLED 27 is the perfect monitoring solution for those who demand the highest quality image and color.

SUMMARY
Screen Size: 27 Inch
Inputs: 12G-SDI
Outputs: 12G-SDI
NITs: 550
Power Supply: 3-pin XLR
Recording: No

About The SmallHD Oled 27 Monitor
OLED 27 is SmallHD’s brightest and largest 4K OLED reference monitor yet, offering the best combination of premium color-accuracy and lightweight, set-ready portability you’ll find in any workflow. OLED 27 delivers up to 550nits of brightness and a 1,000,000:1 contrast ratio for previewing HDR on set, as well as 10-bit, true-to-life color accuracy with 110%DCI-P3 & 135% Rec. 709 color gamuts for precise grading in the suite. OLED 27 is Bolt 4K-compatible and comes with PageOS, the powerful software toolset designed for simplicity and speed up to 4K resolution with features including Waveform, Vectorscope, Color Pipe HDR color-rendering, Monitor Calibration Wizard, and more. If you demand OLED-quality image and color that’s equally at home on location or in post, then this is the monitoring solution for you.

Small4K Video Processing Architecture

Inputs: 4x 12G-SDI , 1x HDMI 2.0
Outputs: 4x 12G-SDI, 1x HDMI 2.0

PageOS Software Platform

4K HDR waveform and scopes*
Multi-View
Simplified HDR Colour Pipe set-up
Monitor Calibration Wizard

Power

Hot-swappable dual inputs
1x 3-pin XLR
1x Dual-GM/VM Battery Plate (sold separately)

Unibody Smart Chassis

Dovetail Mounting Rail for battery andaccessory mounting
2x 2-pin accessory power outputs
Interchangeable mounting points

SDI Video Inputs 4x 12G/6G/3G/HD-SDI
(multiplex coming soon)
SDI Video Outputs 4x 12G/6G/3G/HD-SDI
(multiplex coming soon) HDMI Video Input 1x HDMI 2.0 (4K60) HDMI Video Output (coming soon) 1x HDMI 2.0 (4K60)
Multiview (coming soon) Dual-View & Quad-View
Power Inputs 1x 3-pin XLR [12-34V, 6A max (monitor only)]
[15-34V, 12A max (monitor with accessories)]
1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)
Power Outputs 2x 2pin (12V / 2A combined) (Rear) 1x USB (5V / 2.4A) (Front) 1x USB (5V / 1.5A) (Rear) 1x USB-C (5V / 1.5A) (Rear)
Data I/O 1x SD Card Slot
1x RJ45 Ethernet
1x RJ45 GPI
LUTs 17pt 3D-LUT on output/input
33pt 3D-LUT on output/input (coming soon)
Audio 1x 3.5mm Stereo Headphone Jack (coming soon)
1x 1W Speaker (coming soon)
Mounting Points 1x 110mm VESA-compatible rear mount
26x 1/4-20 mounting points
4x 3/8 mounting points
Software Key Features in all-new OS4.1:
Internal Calibration Wizard
Colour Pipe colour-space formatting
Settings Dashboard for easy access to common settings
Preconfigured Pages
Page Tabs
Customizable False Colour Overlays
Customizable 4K Waveform w/Region of
Interest Highlighting (coming soon)
Improved Function Buttons
Pixel Zoom, Focus Assist, Peaking
Total UI overhaul
Weight (w/handle+feet) 13.16lbs
