SmallHD Cine 13in Monitor

Overview
The Cine 13 monitor is a compact and powerful 4K production monitor designed for on-set creatives. It features a 13-inch IPS LCD screen with a resolution of 3840×2160 and 100% Rec 709 color accuracy. The monitor also has a brightness of 1500+nits, making it suitable for use in full sunlight without the need for a sunhood or viewing tent. It has four 12G-SDI inputs and outputs, as well as one HDMI 2.0 input, and a unibody smart chassis with various mounting options. The monitor also comes with the Small4K™ Video Processing Architecture and the PageOS 4 software platform, which includes useful features such as 4K HDR waveform and scopes and a Monitor Calibration Wizard.

The Cine 13 monitor is designed to be portable, weighing only 6.8lbs, and is suitable for use in various shooting situations. It also has hot-swappable dual inputs, allowing for the use of Gold Mount or V-Mount battery plate attachments. With the SmallHD PageOS software, users can customize their Page Profiles and access features such as personalized frame guides, Focus & Exposure Assist, and high-resolution 3D LUT overlays. The software also includes a histogram, vectorscope, and waveform for precise monitoring. Overall, the Cine 13 monitor is a versatile and reliable tool for professional filmmakers.

Summary
Screen Size: 13.3 Inch
Resolution: 3840 x 2160
Inputs:
12G-SDI
HDMI 2.0
RJ-45
SD card
Outputs:
12G-SDI
3.5mm Jack
HDMI 2.0
NITs: 1500
Power Supply: 4-pin XLR
Recording: No
Included in box
1x 4K HDMI to 4K HDMI Cable (120in/305cm)- CBL-SGL-HDMI-4K-120
1x SmallHD 4K Monitor Feet (Set) ACC-MT-FEET-4K
1x 8GB SD Card (ACC-SD-CARD-8GB-C10)
1x SmallHD Cleaning Cloth (ACC-CLOTH-SMALLHD)
1x 24V Power Supply (Cine 13, 18) 17-3200
1x Mounting Rail for Cine 13 17-5042
1x Premium Monitor Handle for 4K Monitors 17-5413
1x Cine 13 Transport Screen Protector 17-1063

About the SmallHD Cine 13in Monitor
Cine 13 is an agile, brilliantly bright, and pixel-dense 4K production monitor designed for those on-set creatives who require critical focusing capability and a large display. Low-profile in design, this field companion can be rigged for almost any situation. And, weighing in at only 6.8lbs, the Cine 13 is making monitoring in 4K more portable than ever.

The Cine 13” 4K High-Bright Monitor boasts over 1500nits of brightness, ensuring an unobstructed look at your production in full sunlight without the need for a sunhood or viewing tent. The 13-inch screen has a 3840 x 2160 resolution and full 4K clarity, as well as 10-bit color depth for color-accurate images.

Cine 13 features four 12G SDI inputs and outputs as well as one HDMI 2.0 input. The Unibody Smart Chassis offers an Arca Slide on Rail for battery and accessory mounting, a lower mounting rail for ultimate flexibility, and 2x 2-pin accessory power outputs. Hot-swappable dual inputs allow you to add on Gold Mount or V-Mount battery plate attachments.

Meet Our Smart PageOS Software

With the power of SmallHD PageOS software, build customized Page Profiles, and utilize all of the dependable SmallHD features such as personalized frame guides, Focus & Exposure Assist, high-resolution 3D LUT overlays, histogram, vectorscope, waveform, and more.

Screen size 13.3in diagonal
Resolution 3840 x 2160
Brightness 1500+ nits
Backlight Type Edge-lit
Contrast ratio 1300:1
Colour Space 100% Rec. 709
Colour Bit Depth 10 bit (8+2)
Video Inputs/Video Outputs 4x 12G-SDI and 1x HDMI 2.0 (4Kp60)
(multiplex coming soon)
Multiview Dual-View and Quad-View (coming soon)
USB Plug and Power 1x USB (5VDC / 2.4A) (Front)
1x USB (5VDC / 1.5A) (Rear)
1x USB-C (5VDC / 1.5A) (Rear)
Power Inputs 1x 4-pin XLR
(210W max, 12-34VDC, 18A max)
Power Outputs 2x 2-pin Lemo Connector
(12VDC / 2A combined)
Software PageOS 4 Key Features:
Internal Calibration Wizard
Colour Pipe color-space formatting
Settings Dashboard for easy access to common settings
Preconfigured Pages
Page Tabs
Customisable False Colour Overlays
Customisable 4K Waveform
W/ Region of Interest Highlighting (coming soon)
Improved Function Buttons
Pixel Zoom, Focus Assist, Peaking
Total UI overhaul
Weight (with handle and feet) 6.8lbs / 3.09kg

13.3in / 34cm IPS LCD
1500+nits Brightness
3840×2160 Resolution
100% Rec 709 Colour
PageOS 4 software platform: 4K HDR waveform and scopes, Dual & Quad-View, Colour Pipe colour rendering, Monitor Calibration Wizard
Small4K™ Video Processing Architecture – Inputs: 4x 12G-SDI , 1x HDMI 2.0*, Outputs: 4x 12G-SDI, 1x HDMI 2.0
Unibody Smart Chassis -Smart Slide-On Rail for battery and accessory mounting, 2x 2-pin accessory power outputs
Lower mounting rail included for ultimate flexibility
1x 4-pin XLR
Hot-swappable dual inputs
Connector Type: 1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI
