Sennheiser SKM AVX-835S-3 Handheld Transmitter

Overview
The SKM AVX-835S is a high-performing handheld transmitter designed for the AVX digital wireless microphone system. It boasts a very fast setup process and can be easily plugged directly into an XLR audio input. Its ultra compact receiver and metal housing make it a convenient and durable choice for audio recording.

In addition to its efficient setup, the SKM AVX-835S offers a range of features that optimize its performance. These include the ability to switch on and off using P48 Phantom power, auto frequency management, and AES 256 encryption for secure audio transmission. The microphone also has a mute switch for full control during interviews and is made in Germany for top-notch quality.

Summary
Battery Mount / Type: Li-ion Battery Pack
Connectivity: Radio Frequency (RF)
Connector type: XLR
Included in box
1x Handheld transmitter
1x MMD 835 microphone head
1x Energy pack
1x Microphone clamp
1x Pouch

About the Sennheiser SKM AVX-835S-3 Handheld Transmitter
The SKM AVX-835S is the handheld transmitter for the AVX digital wireless microphone system. The robust dynamic directional microphone blocks unwanted side noises in loud environments. It is the ideal choice for street interviews.

The SKM AVX-835 handheld transmitter for the AVX system is fully self configuring which makes the setup of radio frequencies a thing of the past. The AVX matches perfectely to your camera’s input sensitivity without having to adjust the audio level on the microphone. The mute switch on the handheld transmitter gives you full controll during your interview.

Colour Black
Frequency Response 20 Hz – 20000 Hz
THD, total harmonic distortion typ. 0.1 %
Weight Receiver: 87 g (incl energy pack)
Audio Input 3.5 mm mini jack
Audio Output XLR
Operating Temperature -10 °C – + 55°C
Signal-to-noise Ratio > 90 dB(A)
RF Output Power adaptive up to 250mW (peak) country specific
Operating Time > 4h (Receiver), typ 15 h (Transmitter with LiIon energy pack)
Modulation GFSK (DECT)
Audio Output Level -30 dBu – 0 dBu in 4 Steps
Battery Specification Li-Ion 3,7 V DC
> 120 dB(A)
Frequency Band 1880 – 1930 MHz (Country specific)
Sampling Rates 24 bit / 48 kHz
Latency 19ms

Very fast setup
Plugs directely into XLR audio input
Ultra compact receiver
Switches on/off by P48 Phantom power
Optimized dynamic range
Auto frequency management
AES 256 encryption
License free
Mute switch
Metal housing
Made in Germany
