PortKeys 5.5in IPS Touchscreen Camera Monitor

Overview
The Portkeys LH5P II is a high-quality camera monitor designed for Sony cameras. It features a 5.5-inch IPS touch screen with 2200nit brightness and 4K HDMI 30p signal input and output. The monitor is equipped with a CNC aluminum alloy all-metal shell, providing durability and a sleek look. It also has the ability to control the camera both wired and wirelessly, making it convenient for photographers and videographers.

One of the standout features of the Portkeys LH5P II is its customizable keys. The +/- key can be programmed to control various camera settings such as IRIS, shutter, zoom, frame rate, and ISO. The F1~F4 keys can also be set to function as the camera REC key. Additionally, the monitor offers features like customized peaking range, anamorphic lens calibration, and touch screen focus for wireless control on compatible Sony cameras. With its advanced features and sturdy design, the Portkeys LH5P II is a must-have for any professional photographer or filmmaker.

Summary
Screen Size: 5.5 Inch
Resolution: 1920 x 1080
Inputs: HDMI
Outputs: HDMI
NITs: 2200
Included in box
1x 5.5in Monitor
1x Power Cord
2x 2.4G Straight Head Antenna (wireless to Sony cameras, includes A7S III, A7M IV, A7M III, A1, A9I, A9II, A7C, FX3, RX10, RX0)
1x LANC Control Cable
1x TYPE-C Control Cable
1x Safety Box
1x After Sales Service Card
1x Warm Prompt Card
1x U Disk

About the PortKeys 5.5in IPS Touchscreen Camera Monitor
Portkeys LH5P II 2200nit 5.5″ IPS touch screen camera monitor with 4K HDMI 30p signal input and output. This monitor adopts all-metal CNC aluminium alloy shell, which can control the camera by wired/wireless, and the shortcut key F key can be set to control the camera recording starts and stops. At the same time, it has New Peaking algorithm to capture more focus.

Screen size 5.5in
Dimensions 144x90x30.8mm
Viewing angle 178 degrees H 178 degrees V
Brightness 2200nit
Resolution 1920×1080
Contrast Ratio 1000:1
Weight 285g
Colour depth 10bit (8+2 FRC)
Material Aluminium Alloy + Tempered glass
Input voltage DC 7-24V
Maximum Power 13W
Fan Yes
Interface
Video Input/Output Input Interface- 4K HDMI
Output Interface- 4K HDMI
Support Battery Model Sony NP-F970/F960/F750/F550
5pin aviation power input/output Available 7-24V power supply or NPF series battery to supply power to LH5PII
Can output 5V1A voltage to power other devices
USB-A Firmware update/3D LUT
Audio output 3.5mm headphone jack
REMOTE-A Support wired control of Z CAM, Canon, Sony, Panasonic and BMD
REMOTE-A Support wired control of Tilta Nucleus-N/M
HDMI Signal

4096x2160p@24Hz
3820x2160p@23.97Hz, 24Hz, 25Hz, 29.97Hz, 30Hz
1920x1080p@23.97Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 50Hz, 59.94, 60Hz
1920x1080psf@23.97Hz, 24Hz, 25Hz, 29.97Hz, 30Hz
1920x1080i@50Hz, 59.94Hz, 60Hz
1280x720p@50Hz, 59.94Hz, 60Hz
720x576p@50Hz
720x576i@50Hz
720x480p@50Hz, 59.94Hz, 60Hz
720x480i@50Hz, 59.94Hz, 60Hz

Wired/Wireless Touch Control for Sony Cameras
+/- Key can be Customized to Control IRIS, Shutter, Zoom, Frame Rate, and ISO
F1~F4 Key can be set to Camera REC Key
CNC Aluminum Alloy All-metal Shell
Wired Control of TILTA Nucleus-N/M Motors
New Peaking
Customized Peaking Range(Peaking Frame)
Customized Image Crop & Full-Screen Display
Anamorphic Lens Calibration
Supported Ratio: 1.00X/1.33X/1.42X/1.50X/1.60X/1.66X/1.85X/2.00X/2.35X; And User-Defined Adjustment Range: 0.25X-4.00X
Brightness and RGB Signal Detection Before/after Loading 3D LUT
Touch Screen Focus (Wireless Control) A9II、A7C、FX3、RX10、A7S III、A7IV
