Panasonic AK-UC3300 Camera System

Overview
The AK-UC3300 is a powerful 4K Studio Camera system that boasts a large 11-megapixel sensor, allowing for 4K video output with a horizontal resolution of 2,000 TV lines. This impressive camera also supports 1/100 second high-speed reading to control rolling shutter distortion and has the ability to produce High Dynamic Range (HDR) and ITU-R BT.2020 wide color range when connected to the AK-UCU600. Additionally, the AK-UC3300 supports HD Hi-Speed mode (2x) and has 12G-SDI and TICO over SDI output when connected to the AK-UCU600, making it a versatile choice for a variety of production applications.

Equipped with a large S35mm MOS 4K sensor, the AK-UC3300 is capable of delivering high quality video for broadcast studios, live events, and eSports. The 11-megapixel sensor ensures a resolution of 2000 TV lines and maintains an impressive S/N ratio of 62 dB even at high sensitivities. The camera also has a built-in optical conversion lens, allowing for the use of standard 2/3-type B4 mount lenses. With support for HD High Speed (2x) and Low Skew Mode, the AK-UC3300 is designed for optimal video production in dynamic environments. And with its ability to support both UHD and HD acquisition simultaneously, this camera offers multi-format capability for added convenience.

About the Panasonic AK-UC3300 Camera System
The AK-UC3300, a 4K Studio Camera system equipped with a large S35mm MOS 4K sensor to deliver high quality video. Ideal for a variety of production applications, such as broadcast studio, live events and eSports.

High Quality Picture

The AK-UC3300 has a large 11-megapixel 4K image sensor to achieve resolution of 2000 TV for a richly detailed picture while an S/N ratio of 62 dB or more is maintained at high sensitivities. Built-in optical conversion lens allows standard 2/3-type B4 mount lenses to be used. Additionally High Dynamic Range (HDR) and ITU-R BT.2020 wide color range is supported.

HD High Speed (2x) and Low Skew Mode

The AK-UC3300 UHD Camera system is designed for optimal video production in dynamic environments. In addition to the 2x high-speed HD shooting function, the skew reduction function – realised through high speed scans operating at 1/100 of a second – provides excellent operability when shooting rapid movements such as during sports and live events

Multi-Format Capability

The AK-UC3300 supports UHD and HD acquisition simultaneously providing multi-format support.

UHD 2160/59.94p, 2160/50p, 2160/29.97p,
2160/25p, 2160/23.98p, 2160/29.97PsF,
2160/25PsF, 2160/23.98PsF,
2160/23.98PsF & over 59.94i
HD 1080/59.94p, 1080/50p, 1080/59.94i,
1080/50i, 1080/29.97PsF, 1080/25PsF,
1080/23.98PsF
720/59.94p, 720/50p
HD High Speed 1080/59.94p-120fps, 1080/50p-100fps,
1080/59.94i-120fps, 1080/50i-100fps,
720/59.94p-120fps, 720/50p-100fps

4K video output with horizontal resolution of 2,000 TV lines is possible with a large 11-megapixel sensor.
Supports 1/100 second high-speed reading to control rolling shutter distortion.
Supports High Dynamic Range (HDR) and ITU-R BT.2020 wide color range.(with AK-UCU600 connected)
Supports HD Hi-Speed mode (2x).(with AK-UCU600 connected)
12G-SDI output/ TICO over SDI output /(with AK-UCU600 connected).SMPTE ST2110 supported with optional(with AK-NP600).
