Nikon Nikkor Z 28-135mm F/4 PZ

Overview
Nikon Nikkor Z 28-135mm F/4 PZ is a dedicated Z mount video lens designed for high-definition 8K footage with the ability to crop in post and output in 4K. The lens features a smooth power zoom, video-specific optical design to minimise distortion, and a minimum focus distance of 0.34m to 0.57m. It also supports matte boxes and follow focus units, with a gear pitch of 0.8m for standard follow focus systems.

The lens offers intuitive handling for videographers with customisable rings, a well-positioned zoom lever, and compatibility with cages and mounts. It also features Hi-Res Zoom for extending the zoom range by 2x in 4K, fast and quiet autofocus, and remote zooming capabilities. Additionally, the lens is lightweight, location-ready with dust and drip-resistance sealing, and comes with a rectangular lens hood with a filter window for adjusting 95mm filters.

Summary
Focal Length: 28-135mm
Max Aperture: F4
Lens Format: Full Frame
Lens Type: Zoom
Lens Mount: Nikon Z Mount
Filter Thread: 95mm
Front Diameter: 105mm
Weight: 0-2kg
Included in box
1x Nikon Nikkor Z 28-135mm F/4 PZ
1x LC-95B Lens Cap (front cap)
1x LF-N1 Lens Cap (rear cap)
1x HB-116 Lens Hood
1x CL-C5 Lens Case

About the Nikon Nikkor Z 28-135mm F/4 PZ
Engineered to be exceptional, the NIKKOR Z 28-135mm f/4 PZ lens is a video workhorse. With optics designed to resolve 8k footage straight from the camera, it opens options for solo video shooters and small crews.

Dedicated Z Mount Video Lens

With its impressive rendering power, the NIKKOR Z 28-135mm f/4 PZ lens can resolve high-definition 8K video footage that allows plenty of flexibility to crop in post and output in 4K. The versatile focal-length range handles wide or close-up shots with ease, while the smooth power zoom lets you quickly frame shots on the go. A minimum focus distance of 0.34 m from 28mm to 50mm, and 0.57 m at 135mm, extends your creative options nicely.

Video-Specific Optical Design

The complex optical construction features 18 elements in 13 groups and minimises distortion at any shooting distance. For the best possible anti-reflection performance, Meso Amorphous Coat significantly reduces unwanted ghosting and flare caused by bright light sources. Footage is remarkably clear, even if shooting under strong sunlight or studio lighting.

Intuitive Handling For Videographers

A yellow ring signifies this is a Z mount video lens, while Nikon’s renowned ergonomics enable comfortable handling. The focus, zoom, and control rings are customisable and different knurling on each lets you identify them without looking. The zoom lever is well positioned for operating the camera at waist or shoulder height, and its textured surface prevents fingers from slipping.

Supports Matte Boxes And Follow Focus Units

The NIKKOR Z 28-135mm f/4 PZ lens is compatible with a wide range of cages and mounts, and is shaped so that it’s easy to attach a matte box. The focus ring has a gear pitch of 0.8 m so that you can work with standard follow focus systems, while the rectangular hood (included) boasts a filter adjustment window that lets you keep using the 95 mm filters you have.

Model NIKKOR Z 28-135 f/4 PZ
Mount Nikon Z mount
Focal Length 28-135 mm
Maximum Aperture f/4
Lens Construction 18 elements in 13 groups (4 aspherical lenses, 3 ED lenses, 1 ED aspherical lens)
Angle of View (Full Size/FX Format) 75°-18°10′
Angle of View (APS-C/DX Format) 53°-12°
Focusing System Internal focusing (IF) system
Vibration Reduction (VR) None
Vibration Reduction (Tripod/Monopod Use) None
Diaphragm Blades 9 (rounded diaphragm opening)
Aperture System Automatic aperture with electromagnetic diaphragm mechanism
Aperture Range f/4-22
Minimum Focus Distance 0.34 m (wide end) / 0.57 m (telephoto end) from focal plane
Maximum Reproduction Ratio 0.15x (wide end) / 0.25x (telephoto end)
Weight Approx. 1,210 g (with tripod collar) / Approx. 1,120 g (without tripod collar)
Maximum Diameter × Length Approx. 105 mm × 177.5 mm
Lens Mount Diameter Approx. 104 mm
Filter-Attachment Size 95 mm
Color Black
AF Drive Motor Stepping motor (STM)
ARNEO Coat None
Meso Amorphous Coat Yes
Fluoride Coat Yes
Focus Mode Switch Yes
Front Lens Cap LC-95B Lens Cap
Rear Lens Cap LF-N1 Lens Cap
Lens Hood HB-116 Lens Hood
Lens Case CL-C5 Lens Case
Compatible Accessories 95mm screw-in filter (sold separately)

Dedicated Z mount video lens: supports high-definition 8K footage that allows plenty of flexibility to crop in post and output in 4K. Yellow ring around the lens mount indicates that this is a video lens.
Smooth, balanced power zoom: internal motor smoothly manages the 28-135mm focal-length range and ensures a stable centre of gravity.
Video-specific optical design: minimises distortion at any shooting distance. Meso Amorphous Coat counters ghosting and flare, and focus breathing is supressed.
Dynamic close ups: minimum focus distance of 0.34 m from 28mm to 50mm, and 0.57 m at 135mm.
Ease-in/ease-out: for natural tapering of zoom speed, no external zoom unit necessary.
Linear manual focusing: for accurate, repeatable focus adjustments.
Focus ring with 0.8 m gear pitch: compatible with standard follow focus units. The lens is also shaped so it’s easy to attach a matte box.
Position record and recall: available when shooting remotely or in ‘normal’ mode. 11 zoom speeds: can be assigned to the zoom lever or the camera’s Fn buttons.1
Customisable zoom ring: angle and direction of rotation can be adjusted via the camera menu.2 Smooth handling: zoom lever for precise fingertip control and L-fn buttons on side and top of lens.
Hi-Res Zoom: extends the zoom range by 2x when shooting in 4K, resolution and depth of field are maintained. Synchro mode combines the operation of power zoom and Hi-Res Zoom.
Fast, quiet autofocus: driven by Nikon’s (STM) stepping motor.
Remote zooming: via a PC with NX Tether installed, or a smart device running SnapBridge or NX Field.
Lightweight: handheld, gimbal, and tripod-friendly weight of just 1210 g (including tripod collar).
Location ready: high-performance dust- and drip-resistance sealing. Nikon’s fluorine coat protects the front element and keeps it easy to clean.3
Rectangular lens hood (included): with a filter window for adjusting 95 mm filters while the hood is attached.

Note:

1 11 different zoom speeds: supported by Z9, Z8, and Z6III. Available on Z5, Z6II, and Z7II after firmware updates. Not available on Z6 or Z7.

2 The direction of the zoom ring can be reversed via custom settings in the camera menu. A camera firmware update may be required.

3 The lens is not guaranteed to be dust- and drip-resistant in all situations and under all conditions.
