Powerful SDI/BNC to HDMI Video Converter

Kiloview CV180 SDI multi-function converter can convert SDI-based coaxial signals into HDMI, VGA and AV (CVBS) signal output, and has both frame rate/resolution conversion, color adjustment, image enlargement/reduction and other editing management functions. It supports one input and two output modes as well.

Greatly Compatible with Protocols

SD/HD/3G SDI input together with built-in SDI clock recovery circuit and line equalizer, it can recover attenuation and distortion SDI signal after long-distance transmission;HDMI/VGA/AV(CVBS) output simultaneously supported with self-defined resolution, independent audio output available (either two of them can output at the same time);HDMI/ VGA DDC function supported, it can self-adaptively output the best mode of HDMI/ VGA;OSD menu operation interface supported.

Video Conversion & Enhancement

CV180 highlights professional color adjustment, 3D noise reduction, interlace/ progressive video conversion, video scaling up/down conversion and frame rate conversion etc., which can guarantee the professional image conversion quality.

Analog Audio

Independent analog audio output is available for Kiloview CV180, which is convenient for your video production.

Applications

Our CV180 are suitable for all scenarios that need to convert SDI signals to SDI, HDMI, VGA, or AV (CVBS) signal output, such as broadcast and television program editing, video teaching and training, high-definition video information release, high-definition video long-distance transmission, Video conferencing, multimedia advertising and video security monitoring and other fields.

Kiloview KV-CV180

Kiloview KV-CV180 is a broadcast level multifunctional video converter which can convert SDI to HDMI, VGA and AV(CVBS) with functions of frame conversion, resolution conversion, image scale up/ down, colour conditioning, image enhancement and adjustment, and more. It supports 1 input and 2 outputs.

Kiloview CV180 video converter is suitable for the applications that need to convert SDI to (HDMI/VGA/AV(CVBS)/independent audio, etc.) such as broadcast, video teaching and training, HD video information release, HD videolong-distance transmission, video conferencing, multimedia advertising and video security monitoring.

High compatibility, wide application

• SD/HD/3G SDI input together with built-in SDI recovery circuit and line equaliser, it recovers attenuation and distortion SDI signal after long-distance transmission
• SDI/HDMI/VGA/AV(CVBS) output simultaneously supported self-defined resolution, independent audio output available
• Support 1 input and 2 outputs
• Advanced setting or firmware upgrade is available by connecting PC via USB.

High quality image conversion and image enhancement processing, making sure theimage quality to broadcast level

• High quality 10bit YUV4:2:2 conversion, ensuring the colour without distortion
• Professional colour adjustment, 3D noise reduction, progressive/interlace video conversion, video scaling up/down andframe rate conversion etc., which can guarantee the professional image conversion quality
• Blue screen display while signal loss.

High quality, 24h continuous working

• High quality chips, capacitors, PCB board, interface adopted to ensure the stability of the device, making 24h continuous working available
• EMC and HDMI test passed, high compatibility and reliability.
• SD/ HD /3G SDI to HDMI/ VGA /AV( CVBS)
• High compatibility
• Frame/ resolution conversion
• Remote control
• Web configuration management
• 7*24h continuous working
