Eizo ColorEdge 31.1in Professional 4K Monitor

Overview
Built in Sensor to Automate Your Workflow The ColorEdge CG319X is equipped with a built-in sensor which can be set to calibrate the monitor automatically at designated times. This eliminates the need for a third-party calibration device and ensures your screen stays color-accurate. In addition, the monitor features the latest sensor technology, which allows you to continue using it even during recalibration. The sensor swings onto the screen, taking up minimal space, so your work remains uninterrupted.

ColorNavigator 7 Colour Management Software ColorNavigator 7 is the latest calibration and quality control software for ColorEdge color management monitors. It combines all the features of EIZO’s previous color management software, ColorNavigator 6 and ColorNavigator NX, to create a new and improved solution for creatives in a range of fields. The proprietary software makes calibration simple and produces predictable results for photography, design, print, and video creation.

Summary
Recording: No
Included in box
1x DisplayPort Cable (2 m)
1x Mini DisplayPort – DisplayPort Cable (2 m)
1x HDMI Cable (2 m)
1x AC power cord
1x USB Type-A – USB Type-B cable (2 m)
1x Setup guide
1x Adjustment certificate
1x ScreenCleaner
1x Monitor hood
1x Warranty card
4x VESA mounting screw

About the Eizo ColorEdge 31.1in Professional 4K Monitor
Built in Sensor to Automate Your Workflow

The ColorEdge CG319X is equipped with a built-in sensor which can be set to calibrate the monitor automatically at designated times. This eliminates the need for a third-party calibration device and ensures your screen stays color-accurate. In addition, the monitor features the latest sensor technology, which allows you to continue using it even during recalibration. The sensor swings onto the screen, taking up minimal space, so your work remains uninterrupted.

ColorNavigator 7 Colour Management Software

ColorNavigator 7 is the latest calibration and quality control software for ColorEdge color management monitors. It combines all the features of EIZO’s previous color management software, ColorNavigator 6 and ColorNavigator NX, to create a new and improved solution for creatives in a range of fields. The proprietary software makes calibration simple and produces predictable results for photography, design, print, and video creation.

ColorNavigator Network Quality Control Software

ColorNavigator Network provides centralized quality control of ColorEdge monitors that have ColorNavigator 7 or NetAgent installed. Administrators can set color modes, schedule self-calibration, register or adjust asset management settings, and other tasks whether the monitors are local or remote. ColorNavigator Network is hosted on a secure cloud server to free you from the initial investment and running costs of providing your own server.

DCI 4K Resolution

The ColorEdge CG319X displays the DCI 4K standard (4096 x 2160) which is more than four times that of full HD (1920 x 1080). It’s ideal for creating, editing, and referencing with 2D and 3D CGI, VFX, compositing, and color grading.

Large 31.1″ Screen

Whether you are creating, editing, or checking your work, this screen offers ample space to focus on 4K content. At a dense 149 ppi, it’s suited for not only video editing but also photo retouching and printing.

HDR Gamma Support

The ColorEdge CG319X is equipped with HLG (hybrid log-gamma) and the PQ (perceptual quantization) curve for displaying and editing HDR (high dynamic range) video content. The optimized gamma curves render images to appear more true to how the human eye perceives the real world compared to SDR (standard dynamic range). This ensures professional creators can reliably display HDR content for editing and color grading.

Vivid Colours Reproduced to Industry Standards

This wide-gamut monitor faithfully reproduces 98% of the DCI-P3 standard used in digital cinema and supports the Rec. 2020 standard used in broadcasting. In addition, it covers 99% of the Adobe RGB color space so images shot in Adobe RGB will be displayed correctly. The wide color gamut also ensures reproduction of almost the entire ISO-coated and US web-coated CMYK color spaces used in printing.

True Black Display

In compliance with the DCI standard, the ColorEdge CG319X offers a high contrast ratio of 1500:1* for producing true blacks that are otherwise difficult to display on a typical LCD monitor. When viewing the screen from an angle in a dimly lit room, dark tones typically appear washed out due to the display characteristics of LCD backlights. The CG Series is equipped with a retardation film which allows tones to retain their depth even when viewed from an angle.

3D LUT for Accurate Colour Display

A 3D LUT is included which adjusts colors individually on an RGB cubic table. With the supported ColorNavigator NX software’s emulation function, creators can check how content will appear to their audience. The 3D LUT also improves the monitor’s additive color mixture (combination of RGB), which is a key factor in its ability to display neutral gray tones.

10-Bit Simultaneous Display

The ColorEdge CG319X offers 10-bit simultaneous display* from a 24-bit look-up-table (LUT) which means it can show more than one billion colors simultaneously. This is 64 times more colors than you get with 8-bit display, resulting in smooth color gradations and reduced Delta-E between two adjacent colors.
*A graphics board and software which support 10-bit output are also necessary for 10-bit display. Equipment that supports DeepColor is required for 10-bit display when connected via HDMI.

Broadcast Cinema Presets

Preset modes for DCI-P3, Rec. 709, and Rec. 2020 ensure you can work in the appropriate color spaces and gamma values. In addition, preset modes for PQ (DCI and Rec. 2100) and HLG (Rec. 2100) are available for viewing HDR content. With the built-in calibration sensor, you can conveniently adjust or maintain the brightness setting for each preset.

Luminance Warning

The ColorEdge CG319X includes a PQ and HLG Clipping function that shows the areas of an image which display at brightness levels higher than the current setting. The areas which cannot be displayed at the correct brightness with the current settings are shown in yellow or magenta. PQ and HLG Clipping can be viewed for brightness levels of 300, 500, 1000, and 4000 cd/m2.

Safe Area Marker

A safe area marker designates the area of the screen that will be displayed when the monitor is connected to a particular device. This allows you to check that subtitles and other text will be visible. The color of the marker is changeable to ensure it remains with any imagery.

Aspect Marker

An aspect marker designates the areas of the screen size that will be shown on a display device when you input DCI 4K (4096 x 2160) or DCI 2K (2048 x 1080). This allows you to confirm how the screen size and composition of the scene will appear in other viewing environments. Aspect ratios 1.85:1, 2.35:1, and 2.39:1 can be selected.

4K Zoom Function

Enlarge areas of the screen to confirm small details and check focus accuracy in photos using the 4K zoom function. It is quickly and easily accessible using the monitor’s front buttons.

Rec. 709 Out of Gamut Warning

The monitor includes a Gamut Warning preset. When selected, the areas of a Rec. 2020 image that cannot be reproduced using Rec. 709 are clearing indicated by converting them to shades of gray. An additional mode called Rec. 709 Clipping allows the editor to view Rec. 2020 images within the Rec. 709 color space, simulating how it would look to their audience in an HDTV environment.

Adjusted at the Factory for Smooth Color Gradations

The gamma level for each ColorEdge monitor is adjusted at the factory by measuring the R, G, and B gamma values from 0 – 255, then using the monitor’s 24-bit look-up-table (LUT) to select the most appropriate tones and achieve the desired value. This ensures the smoothest color gradations in your images.

Stable Display Using Industry-First AI

The color and brightness of an LCD monitor can shift due to changes in ambient temperature and the temperature of the monitor itself. ColorEdge monitors are equipped with a temperature sensor for accurately measuring the temperature inside the monitor, as well as estimating the temperature of the surrounding environment. With this temperature sensing and estimation technology, the monitor adjusts in real-time so gradations, color, brightness, and other characteristics continue to be displayed accurately. Furthermore, EIZO uses AI (artificial intelligence)* in the estimation algorithm of the CG319X so it can distinguish between various temperature changing patterns to calculate even more accurate correction.

Stable Coluor in 3 Minutes

A typical monitor takes 30 minutes or more for its brightness, chromaticity, and tone characteristics to stabilize. The ColorEdge CG319X takes a mere 3 minutes. Whether you are working in a studio or taking the monitor with you on location, you get reliable color display soon after turning the monitor on.

Uniformity Across the Screen

LCD monitors commonly exhibit fluctuations in brightness and chromaticity across the screen, affecting color accuracy. To counter this, ColorEdge monitors are equipped with EIZO’s patented digital uniformity equalizer (DUE) technology which corrects deviations in every tone across the screen to ensure stable display.

Minimized Reflections with Non-Glare Panel

The monitor is equipped with an IPS non-glare panel for high visibility. It also uses dimming technology to minimize flicker and help prevent eye fatigue for a more comfortable working environment.

Wide Viewing Angles with IPS Panel

The 178° wide viewing angles afforded by the IPS panel technology allow two or more people to view the screen at once with little change in color or contrast.

Light Shielding Hood

The CG Series comes bundled with a shading hood that effectively prevents glare on the monitor’s screen caused by ambient lighting. The ColorEdge CG319X’s shading hood attaches to the monitor magnetically. This allows the users to attach the hood quickly and easily without needing to connect separate parts.

Ergonomic Stand for Comfort and Convenience

Adjust the screen to the most comfortable angle and reposition it to show your work to a colleague or client. The monitor comes with a versatile stand that offers height, tilt, and swivel adjustments. The stand is also equipped with a quick release that allows you to easily remove the screen from the stand with a single touch.

Multiple Inputs

The ColorEdge CG319X is equipped with two DisplayPort and two HDMI inputs. The monitor’s HDMI and DisplayPort inputs support DCI 4K at 60p. HDMI input supports 12-bit 4:2:2 at 50/60p and DisplayPort input supports up to 10-bit 4:4:4 at 50/60p.

PANEL
Type: IPS
Backlight: Wide-Gamut LED
Size: 31.1″ (78.9 cm)
Native Resolution: 4096 x 2160 (17:9 aspect ratio)
Viewable Image Size (HxV): 698.0 x 368.1 mm
Pixel Pitch: 0.170 x 0.170 mm
Pixel Density: 149 ppi
Display Colours: DisplayPort, HDMI: 1.07 billion colors, 10-bit display (24-bit LUT)
Viewing Angles (H / V, Typical): 178˚, 178˚
Brightness (Typical): 350 cd/m2
Recommended Brightness for Calibration: –
Contrast Ratio (Typical): 1500:1
Response Time (Typical): 9 ms (grey-to-grey)
Colour Gamut (Typical): Adobe RGB: 99%, and DCI-P3: 98%
VIDEO SIGNALS
Input Terminals: DisplayPort (HDCP 1.3) x 2, HDMI (Deep Color, HDCP 2.2 / 1.4) x 2
Output Terminals: –
Digital Scanning Frequency (H / V): DisplayPort: 25 – 137 kHz, 23 – 61 Hz HDMI: 15 – 136 kHz, 23 – 61 Hz
USB
Upstream USB 3.1 Gen 1: Type-B
Downstream: USB 3.1 Gen 1: Type-A x 3 (Battery Charging 10.5 W max. x 1)
USB LAN Adaptor –
POWER
Power Requirements: AC 100 – 240 V, 50 / 60 Hz
Maximum Power Consumption: 140 W
Typical Power Consumption: 52 W
Power Save Mode: 1.2 W or less
Built-In Calibration Sensor: Yes
FEATURES & FUNCTIONS
Brightness Stabilisation: Yes
Digital Uniformity Equaliser: Yes
Preset Modes: BT.2020, BT.709, DCI, PQ_DCI, PQ_BT.2100, HLG_BT.2100, Adobe RGB, sRGB, Calibration
HDR Gamma HLG, PQ curve
PHYSICAL SPECIFICATION
Dimensions (Landscape, W x H x D): 735 x 434 – 588 x 290 mm
Dimensions (Without Stand, W x H x D): 735 x 423 x 71.5 mm
Dimensions (Landscape with Hood, W x H x D): 754.4 x 443.6 – 597.6 x 381.5 mm
Net Weight: 12.4 kg
Net Weight (Without Stand): 8.3 kg
Net Weight (With Hood): 13.3 kg
Height Adjustment Range: 154 mm
Tilt: 35˚ Up, 5˚ Down
Pivot: –
Swivel: 344˚
Hole Spacing (VESA Standard): 100 x 100 mm
ENVIRONMENTAL REQUIREMENTS
Temperature: 0 – 35˚C
Humidity (R.H., non condensing): 20 – 80 %
CERTIFICATIONS & STANDARDS (Please contact EIZO for the latest information) CB, CE, UKCA, TÜV/GS, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TÜV/Ergonomics, TÜV/Color Accuracy (Quick Stability), FograCert Softproofing System (class A)
DEDICATED SOFTWARE
Quick Color Match –
ColorNavigator 7 Supported
INCLUDED CABLES DisplayPort (2 m), Mini DisplayPort – DisplayPort (2 m), HDMI (2 m)
ACCESSORIES AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Adjustment certificate, ScreenCleaner, Monitor hood, Warranty card, VESA mounting screw x 4
WARRANTY 5 Years
Warranty Notes 1) Usage time is limited to 30,000 hours. Brightness of the CG Series is warranted for up to 10,000 hours.
2) Brightness of the CG Series is warranted for up to 10,000 hours if it is used within the recommended brightness of 120 cd/m2 or less and colour temperature between 5000 – 6500 K.
3) Free from bright sub-pixels for 6 months from the date of purchase. With current LCD technology, a panel may contain a limited number of missing or flickering pixels.
