Datavideo CAP-2

OVERVIEW
Datavideo presents the DATACAP2, a powerful HDMI to USB 3.0 Capture Box that allows you to capture video in stunning 1080p50/60 resolution. With its plug and play feature, this converter is compatible with various operating systems, making it a versatile choice for all your video capturing needs.

The DATACAP2 features a USB 3.0 interface, eliminating the need for external power and providing a seamless connection to your computer. Its UVC support and auto-detection capability for video format (resolution and frame rate) make it an efficient and user-friendly device.

One of the standout features of the DATACAP2 is its stereo line in external audio, which can be switched as HDMI embedded audio or external line-in audio. This gives you more flexibility and control over your audio settings, ensuring high-quality sound for your captured videos.

Whether you’re using Windows, Linux, or Mac OS X, the DATACAP2 is compatible with a range of popular software such as Amcap, Google Plus Hangouts, OBS, Skype, VLC, Xsplit Broadcaster, Zoom.us, and more. This makes it a versatile choice for various video capturing and streaming applications.

Experience the power of the DATACAP2 HDMI to USB 3.0 Capture Box and elevate your video capturing capabilities. With its advanced features and seamless compatibility, this device is a must-have for any content creator or video enthusiast. Order yours today and take your videos to the next level!

INCLUDED IN BOX
1x Datavideo DATA-CAP2 HDMI to USB 3.0 Capture Box

About The Datavideo CAP-2
CAP-2 HDMI to USB 3.0 Capture Box is an HDMI-USB Capturing device, which supports up to 1080p50/60. Plug and play in the various operating systems. It features a stereo line in external audio, which can be switched as HDMI embedded audio or external line-in audio. There are more flexible and powerful settings for capturing.

USB 3.0 Interface

No external power is needed.

Plug-and-Play

Support UVC. Operations with video format (resolution and frame rate) auto-detection capability

Compatible with various operating systems

Support Windows: Amcap, Google Plus Hangouts, OBS (Open Broadcast Software), Skype, VLC, Xsplit Broadcaster, Zoom.usLinux: VLC, OBSMac OS X: OBS, Quicktime player, VLC, Facetime.

Stereo line in external audio

Switched as HDMI embedded audio or external line-in audio.

Input 1x HDMI
Output 1x USB 3.0 (Micro B)
Input Video Bandwidth 150MHz (pixel clock rate)
Output Video Bandwidth Up to 350Mbps (USB)
Supported Input & Output Video Formats 1920 x 1080p 60/59.94/50/30/29.97/25/24/23.976
1680 x 1050p 60
1600 x 1200p 60
1440 x 900p 75/60
1400 x 1050p 60
1366 x 768p 60
1360 x 768p 60
1280 x 1024p 75/60
1280 x 720p 60/59.94/50
1024 x 768p 75/60
800 x 600p 75/60
720 x 576p 50
720 x 480p 60
640 x 480p 75/60
Supported Output Video Formats 1920 x 1080p 60/50/30/25/24
1680 x 1068p 60
1440 x 1080p 60
1440 x 896p 60
1360 x 768p 60
1280 x 768p 60
1280 x 720p 60/50
1024 x 768p 60
960 x 536p 60
848 x 480p 60
768 x 576p 60
720 x 480p 60/50
640 x 480p 60
640 x 360p 60
Audio Input HDMI Embedded Audio & 3.5 mm stereo in
Audio Support 2-Channel, 44.1 and 48KHz sample rate, up to 24-bit PCM
Capture Video Format YUY2 (USB3.0), MJPG (USB2.0/3.0)
Firmware Update Via USB
Firmware update USB Port
Power Consumption 2W
Operation Temperature 0~40°C
Storage Temperature -20~60°C
Humidity 20~90% RH
Minimum System Requirement Windows® 7(SP1) / Windows 10 / Windows 8.1 / Windows 7 (x86, x64)
Note: The driver is required for Windows 7 OS
OS X (10.10 or above)
Linux Ubuntu 14.04
PC: Intel® CoreTM i5-4440 3.10GHz + NVIDIA® GeForce® GTX 660 or higher
Laptop: Intel® Core i7-4810MQ + NVIDIA GeForce GTX 870M or higher 4GB RAM or higher”
Dimension (LxDxH) 105 x 68 x 23 mm
Weight 70g

HDMI to USB 3.0 Capture Box
Supports up to 1080p50/60
Features stereo line in external audio, which can be switched as HDMI embedded audio or external line in audio
Plug and play in various operation system
