Cartoni HM2500 Master 25 Fluid Head

Overview
The new MASTER25 is a high-quality Fluid Head designed for studio production and outdoor applications. It can support the latest cameras with a payload capacity of up to 30 kg and is available in both black and grey anodized aluminium. Weighing only 5 kg, it features a tilt range of +/-90° and easy-to-use rings for adjusting the fluid drag and counterbalance. The Head also has convenient brake levers and a horizontal lock for easy setup.

The Master 25 has a 150 mm bowl for stability on tripods or hi-hats and can be directly interfaced with most pedestals. It comes with a sliding camera plate that is compatible with competitor gear and offers a perfect balance and super-smooth fluid drag for precise camera movements. The Head also includes a single telescopic pan bar, with the option to add a second one. Overall, the Master 25 is a competitively priced, versatile and high-performance Fluid Head for professional camera operators.

Summary
Max Payload: 30kg
Included in box
1x Master 25 Fluid Head
1x 5 Year Cartoni Warranty

About the Cartoni HM2500 Master 25 Fluid Head
The new MASTER25 presented in its classy Black & Gold design, as a tribute to the famed CARTONI Fluid Heads of yesteryear, is a robust, yet lightweight Fluid Head. Designed to support the latest cameras complete with long lens, viewfinders, prompters and pan bar controls for new studio production as well as OB/ENG/EFP applications, with a payload capacity of up to 30 kg (66 lbs). The Master 25 is also available with grey anodized aluminium.

The lightweight 5 kg (11 lbs) Master 25 features a tilt range of +/-90° and easy to use rings which allow the camera operator or grip to preselect the continuously adjustable fluid drag and counterbalance on a numerical scale from 0 to 10.

Both the pan and tilt brake levers are easy to reach, and the Head features a convenient horizontal lock for setup.

With a 150 mm bowl, it offers a wide and stable base on tripods or hi-hats. The Head base includes 4 bolt threads for direct interface to most of the Pedestals.

Additionally, the Camera platform is equipped with a sliding Camera plate, compatible with competitor gear as the Vinten Vision 250, with standard 11 cm plate or 22 cm extra-long plate for balancing off-set Camera configurations.

The Master 25 is the ultimate premium do-it-all competitively priced Head, with a combination of perfect balance and a super-smooth, continuously variable patented fluid drag on pan and tilt modes, perfectly suited for the camera operators needs.

That means the Head can precisely track slow moving objects and whip pan in an instant.

It comes with a single telescopic pan bar, while the second is optional.

Minimum Payload Capacity 3 kg 7 lbs
Maximum Payload Capacity 30 kg 66 lbs
Weight 4.4 kg 9.7 lbs
Bowl Diameter 150 mm
Fluid Drag Continuous
Counterbalance Continuous
Pan Range 360°
Tilt Range +/-90°
Temperature Range -40°/+60°
