OVERVIEW
Introducing the Canon Sumire 7 Lens Bundle – PL Mount, a set of prime lenses specially designed to give your footage a subtle, cinematic look. With a PL mount and full-frame coverage, these lenses offer a unified warm colour tone and fast apertures for beautiful bokeh. Fine focusing and consistent gear placements make this bundle a must-have for any filmmaker.
Each lens in this package, including the CN-E 14, 20, 24, 35, 50, 85, and 135 mm, has been carefully crafted to offer delicate and subtle rendering of your subject. The fast apertures and precise manual control allow for careful creative expression, while the unique optical design adds a nuanced look to the lens’ wider aperture settings.
The PL mount with full-frame coverage offers wide compatibility options for PL mount 35mm Full-Frame and Super 35mm cameras. And for added convenience, these lenses can also be changed to an EF mount at any authorized service facility.
One of the standout features of the Sumire primes is their unified warm colour tone, inherited from the Canon cinema lens range. This makes it easy to change lenses without affecting the overall colour balance of your footage.
With a fast T-number and 11-blade iris, these lenses offer a bright and beautiful bokeh. The lens design also significantly reduces focus breathing, ensuring your footage stays sharp and in focus. And with carefully developed focus resistance, delicate focus adjustments can be made over a 300-degree rotation angle.
Finally, the Sumire primes offer consistency in both filter and gear placement. All lenses accept 105mm screw-on filters and have a 114mm diameter lens front, making it easy to switch between lenses without having to adjust your filters. Additionally, the gears are consistently positioned for ease of use, allowing for smooth and seamless transitions between lenses.
Don’t miss out on this amazing offer – the Canon Sumire 7 Lens Bundle – PL Mount is the perfect package for any filmmaker looking to add a subtle, cinematic touch to their footage. Upgrade your gear and capture every detail with ease using these beautifully refined lenses.
SUMMARY
Focal Length:
135mm
14mm
20mm
24mm
35mm
50mm
85mm
Max Aperture:
T/1.3
T/1.5
T/2.2
T/3.1
Lens Mount: PL Mount
Front Diameter: 114mm
Weight: 0-2kg
INCLUDED IN BOX
1x CN-E 14mm Lens
1x CN-E 20mm Lens
1x CN-E 24mm Lens
1x CN-E 35mm Lens
1x CN-E 50mm Lens
1x CN-E 85mm Lens
1x CN-E 135mm Lens
About The Canon Sumire 7 Lens Bundle – PL Mount
Subtle, cinematic and expressive. Yet beautifully refined. Designed to offer delicate and subtle rendering of a subject, these seven prime lenses offer fast apertures and precise manual control with a crafted focus bokeh aimed at careful creative expression.Capture every detail with ease
Specially designed ‘cinematic look’:
A unique optical design offers a nuanced look at the lens’ wider aperture settings, subtly modifying textural renderings for pleasing bokeh with superb expressiveness.
PL mount with Full-Frame coverage:
The lens offers wide compatibility options for PL mount 35mm Full-Frame and Super 35mm cameras and can be changed to an EF mount at any authorised service facility.
Unified warm colour tone:
Sumire primes inherit the same subtle warm colour tone from the Canon cinema lens range, making it easy to change lenses without affecting colour balance.
Fast and bright with beautiful bokeh:
A fast T-number is thanks to a large lens diameter and together with an 11-blade iris, offers richer levels of bokeh. The lens design also significantly reduces focus breathing.
Fine focusing with filter and gear consistency:
With carefully developed focus resistance, delicate focus adjustments can be made over a 300-degree rotation angle. All lenses accept 105mm screw-on filters, have a 114mm diameter lens front and have consistently positioned gears for ease of use.
Included Focal Lengths 14, 20, 24, 35, 50, 85 and 135mm
Mount PL Mount (Interchangeable to EF at authorized service facility)
FOCAL LENGTH 14mm
T STOP T 3.1
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 104.3° × 81.2°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 82.6° × 52.5°
MINIMUM OBJECT DISTANCE (from sensor) 0.20 m／8″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 25.2 × 16.8 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 17.2 × 9.7 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 86.0 mm
APPROX. MASS 1.2 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
FOCAL LENGTH 20mm
T STOP T 1.5
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 84.0° × 61.9°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 63.2° × 38.1°
MINIMUM OBJECT DISTANCE (from sensor) 0.3 m／12″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 33.8 × 22.5 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 23.1 × 13.0 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 93.5 mm
APPROX. MASS 1.2 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
FOCAL LENGTH 24 mm
T STOP T 1.5
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 73.7° × 53.1°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 54.3° × 32.1°
MINIMUM OBJECT DISTANCE (from sensor) 0.3 m／12″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 28.8 × 19.2 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 19.7 × 11.0 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 93.5 mm
APPROX. MASS 1.2 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
FOCAL LENGTH 35 mm
T STOP T 1.5
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 54.4° × 37.8°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 38.7° × 22.3°
MINIMUM OBJECT DISTANCE (from sensor) 0.3 m／12″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 20.2 × 13.5 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 13.8 × 7.7 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 93.5 mm
APPROX. MASS 1.1 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
FOCAL LENGTH 50 mm
T STOP T 1.3
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 39.6° × 27.0°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 27.6° × 15.7°
MINIMUM OBJECT DISTANCE (from sensor) 0.45 m／18″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 25.0 × 16.7 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 17.1 × 9.6 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 93.5 mm
APPROX. MASS 1.1 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
FOCAL LENGTH 85 mm
T STOP T 1.3
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 23.9° × 16.1°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 16.5° × 9.3°
MINIMUM OBJECT DISTANCE (from sensor) 0.95 m／3′ 2″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 34.4 × 22.9 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 23.5 × 13.2 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 93.5 mm
APPROX. MASS 1.3 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
FOCAL LENGTH 135 mm
T STOP T 2.2
NUMBER OF IRIS BLADES 11 Blades
ANGLE OF VIEW:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 15.2° × 10.2°
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 10.4° × 5.9°
MINIMUM OBJECT DISTANCE (from sensor) 1.0 m／3′ 3″
OBJECT DIMENSIONS AT MINIMUM OBJECT DISTANCE:
Aspect ratio 1.5:1 Screen dimensions 36.0×24.0mm 21.1 × 14.1 cm
Aspect ratio 1.78:1 Screen dimensions 24.6×13.8mm 14.4 × 8.1 cm
FRONT DIAMETER Φ114 mm
APPROX. SIZE 118.4 × 118.4 × 107.6 mm
APPROX. MASS 1.4 kg
PITCH OF FOCUS GEAR:
Gear Pitch 0.8
Focus Dia. 116.8 mm
Iris Dia. 100.8mm
Specially designed ‘cinematic look’
PL mount with Full-Frame coverage
Unified warm colour tone
Fast and bright with beautiful bokeh
Fine focusing with filter and gear consistency
