OVERVIEW
A new era in image quality
New standards in high resolution stills, and phenomenal 8K video quality to match. The EOS R5 advances image quality to a whole new level for stills and movies with a blistering 20fps electronic shutter or 12fps mechanically. The EOS R5 is a mirrorless camera that combines the best of both worlds, delivering exceptional performance for both photography and videography.
Professional mirrorless redefined
Whatever you shoot, however you shoot it, the Canon EOS R5 will let you be creative in ways you simply couldnt before. With its 45 megapixel full-frame CMOS sensor, advanced AF using deep-learning artificial intelligence, and in-body image stabilisation, this camera is a game-changer for professionals and amateurs alike.
See detail like never before
The next-generation 45 megapixel full-frame CMOS sensor captures incredible clarity, low noise, and wide dynamic range. Paired with Canons advanced RF lenses, this camera delivers stunning images with extraordinary detail and colour accuracy.
Stay sharp, stay focused
The Canon EOS R5 features Dual Pixel CMOS AF II, which is lightning-fast to focus and boasts 5940 AF selectable positions, covering virtually 100% of the frame. This means fast-moving subjects are kept sharp, even when moving quickly and unpredictably, while Face/Eye detection ensures perfect focus for portraits.
Ground-breaking intelligent AF
The cameras autofocus is programmed using a deep-learning AI, first developed for the ground-breaking EOS-1D X Mark III. This enables the EOS R5 to recognize and track a subjects face and eyes with new levels of accuracy and precision, even when viewed from the side. This tracking ability is also available when photographing animals and motor vehicles, making the EOS R5 a versatile tool for all types of photography.
Ultimate speed, ultimate quality
The Canon EOS R5 is a powerhouse when it comes to speed and image quality. With the ability to capture 45 megapixel, full-frame images at a staggering 20fps in complete silence and with full autofocus tracking, this camera is perfect for capturing fast-paced action. And for situations that require it, a mechanical shutter is also available, allowing for class-leading shooting speeds of up to 12fps.
Advanced wireless connectivity
The EOS R5 uses an always-on Bluetooth Low Energy connection to maintain a continuous link with a smart device. This allows photographers to easily browse, review, and transfer images, as well as shoot remotely using the Canon Camera Connect app. The camera also features dual band Wi-Fi for fast and secure image delivery.
RF24-105mm F4L IS USM Lens
The Canon EOS R5 comes with the RF24-105mm F4L IS USM lens, featuring fast, silent, Nano USM technology. This compact and lightweight lens offers 5-stops of image stabilization and high optical quality, making it the perfect all-purpose lens for everyday photography and filmmaking.
The RF mount
The RF mount at the heart of the EOS R System is designed to maximize lens design possibilities. It features a short back focus distance, allowing for more compact lens designs with higher image quality. The RF mount also supports a wide range of RF lenses, making the EOS R5 a versatile camera for any type of photography or videography.
SUMMARY
Native ISO: ISO 100
Lens Mount: Canon RF
Audio Inputs: 1 x 3.5mm Mic Input
Image Stabilisation: Yes
Battery Mount / Type: LP-E6NH
Media Type: SD/SDHC/SDXC
Photo Resolution: 45 megapixels
Sensor: CMOS
Video Outputs: 1x HDMI
Weight: 0-2kg
Wi-Fi: Yes
INCLUDED IN BOX
1 x EOS R5 body
1 x RF 24-105mm F4L IS USM Lens
1 x Camera Cover R-F-5
1 x Strap ER-EOS R5
1 x Battery Charger LC-E6E
1 x Battery Pack LP-E6NH
1 x Battery Pack Cover
1 x AC Cable
1 x IFC Cable IFC-100U + Protector
1 x Lens Cap E-77II
1 x Lens Dust Cap RF
1 x Lens Case LP1319
1 x Lens Hood EW-83N
1 x User Manual Kit
About The Canon EOS R5 + RF24-105mm Kit
Re-think what you know about hybrid mirrorless cameras. Whether you shoot photos, video or a mixture of both, the EOS R5’s uncompromising performance will revolutionise your creativity.
Professional mirrorless redefined
Whatever you shoot, however you shoot it, the EOS R5 will let you be creative in ways you simply couldn’t before. Capture sensational 45 megapixel photos at up to 20 frames per second, or flick a switch for cinematic 12 bit 8K RAW video using the entire width of the camera’s sensor. Advanced AF is programmed using deep-learning artificial intelligence, while in-body image stabilisation works in concert with a lens’s own IS to provide up to 8 stops* of protection against camera shake.
See detail like never before
A next-generation 45 megapixel full-frame CMOS sensor captures incredible clarity, low noise and wide dynamic range: the perfect partner for Canon advanced RF lenses.
Full-frame 45 megapixel CMOS sensor and DIGIC X processor
For sensational clarity and detail whatever you’re shooting – even in bad light up to ISO 51,200.
Introducing Portrait Relighting and Background Clarity
Use Dual Pixel RAW to adjust lighting on your subject’s faces, or to apply clarity to only the background when shooting landscapes.
Stay sharp, stay focused
Dual Pixel CMOS AF II is lightning-fast to focus and boasts 5940 AF selectable positions, covering virtually 100% of the frame. Fast-moving subjects are kept sharp, even when moving quickly and unpredictably, while Face/Eye detection is superb for shallow-depth-of-field portraits.
Ground-breaking intelligent AF
The camera’s autofocus is programmed using a deep-learning AI – first developed for the ground-breaking EOS-1D X Mark III. This enables the EOS R5 to recognise and track a subject’s face and eyes with new levels of accuracy and precision, even when viewed from the side. This tracking ability is also available when photographing dogs, cats and birds, as well as motor vehicles – a first for EOS cameras.
Ultimate speed, ultimate quality. Game-changing performance that will take your creativity to new heights.
Few cameras comes close to the EOS R5. Capture 45 megapixel, full-frame images at a staggering 20fps in complete silence and with full autofocus tracking. And, for situations that need it, a mechanical shutter is also available, allowing class-leading shooting speeds up to 12fps.
Advanced wireless that will transform the way you work
The EOS R5 uses an always-on Bluetooth Low Energy connection to maintain a continuous link with a smart device. Simply launch the Canon Camera Connect app and the camera establishes a fast Wi-Fi connection that enables photographers to browse, review and transfer images, as well as shoot remotely.
Dual band 2.4GHz and 5GHz Wi-Fi
With support for 802.11a, b, g, n and ac standards
Support for FTP and FTPS
For fast secure image delivery direct to your client, either straight from the camera or via the Mobile File transfer app.
RF24-105mm F4L IS USM Lens:
Featuring fast, silent, Nano USM technology, the RF 24-105mm f/4 L IS USM zoom offers photographers and filmmakers a small, lightweight and compact general-purpose lens with 5-stops of image stabilisation and high optical quality and constant aperture. A general purpose, practical zoom for every day photography and filmmaking The RF 24-105mm f/4 L IS USM zoom offers the perfect solution for photographers and filmmakers looking for a professional quality, go anywhere, capture everything lens that can satisfy a wide range of genres.
The RF mount:
The RF mount at the heart of the EOS R System is designed to maximise lens design possibilities and features a short back focus design and wide lens throat. This has made it possible for Canon engineers to design new lenses that weren’t possible before. The RF mount also transmits data faster via a 12-pin connector meaning quicker AF and lens processing using Digital Lens Optimiser stored in the lens itself.
The RF 24-105mm f/4 L IS USM zoom features an innovative Control Ring on the barrel, offering photographers used to manual cameras a familiar and intuitive traditional control over a wide range of customisable settings. This feature gives the photographer greater and faster connection with the camera and allows full concentration to be given to the subject. The Control Ring has a reassuring and familiar ‘click’ as it rotates which can be de-clicked at service, useful for filmmakers wishing to retain the silent characteristics of the lens.
A general purpose, practical zoom for every day photography and filmmaking:
With a hugely versatile 24-105mm focal length range that encompasses the everyday needs of most photographers and filmmakers, the RF 24-105mm f/4 L IS USM zoom is the primary go-to lens particularly suited to subjects such as landscapes, portraits and travel. A fixed f/4 constant aperture ensures exposure consistency throughout the entire zoom range and allows for a smaller, more compact lens design. Weighing in at just 700g, the RF 24-105mm f/4 L IS USM is lightweight, practical and perfect for agile, handheld photography and filmmaking when covering a variety of events and genres in the same day.
Steady, handheld professional performance with 5-stops of image stabilisation:
Advanced image stabilisation of up to 5-stops makes the RF 24-105mm f/4 L IS USM class-leading and among the best performing of any Canon lens, including those in the EF range. The obvious benefit comes when handholding the camera, particularly in low light. The lens works together with compatible EOS R bodies offering powerful combination IS for photographs and movies. A customisable Lens Control Ring is featured on the RF 24-105mm f/4 L IS USM offering the feel of a manual and allowing for the intuitive adjustments of camera settings such as Tv, Av and ISO meaning there is no need to look away from the subject and risk breaking concentration.
Fast, smooth, quiet Nano USM focusing bringing ideal attributes for photos and video:
The RF 24-105mm f/4 L IS USM is the first L-series lens to feature Canon’s pioneering and beautifully silent Nano USM motor technology. Nano USM offers very fast focusing for photographers and is especially useful for filmmakers when smooth focusing is a must for natural looking focus transitions, giving superb control and smooth tracking of the subject as it moves away or towards the camera.
Legendary L-series image quality for outstanding detail, depth and sharpness:
Using a combination of Air Sphere Coating (ASC) and Super Spectra Coating prevents ghosting and flare. Air Sphere Coating (ASC) technology combines traditional anti-reflective technology with a low refractive index which prevents problems like flare and ghosting degrading image quality. An aperture made up of nine blades produces a circular aperture for pleasing out of focus blur and attractive bokeh, resulting in much more natural looking highlights and smooth backgrounds, especially when shooting movies. Achieve high contrast images right across the frame and throughout the entire zoom range thanks to three aspherical lens elements which correct spherical aberration, distortion, and astigmatism. Aspherical lens elements help to compensate for distortion and compensate or eliminate spherical aberrations. They also allow for a more compact lens design. UD lenses reduce axial chromatic aberration and chromatic aberration for richly defined images full of sharpness and colour. UD glass features a low refractive index and low dispersion with performance significantly better than ordinary optical glass.
Smart, professional design, built to accompany you everywhere, every day:
The RF 24-105mm f/4 L IS USM has been designed with performance as well as durability at its heart. Being an L-series lens, weather-sealing is exceptional and offers excellent resistance to dust, moisture and vibrations. Fluorine coatings used on the front and rear lens surfaces are highly dust and dirt resistance and allow the lens outer elements to be cleaned easily. This means the lens can withstand the rigours of professional life and be easy to clean, especially in dusty or humid climates. As an everyday ‘go-to’ lens the RF 24-105mm f/4 L IS USM versatility is exceptional. As well as super-fast focusing, full-time manual focusing for creative control is possible thanks to a delightfully weighted focus ring with refined resistance for precise adjustments. A minimum focus distance of 45cm and a zoom ring lock makes the lens highly flexible plus the provided EW-83N lens hood takes care of lens flare plus provides additional protection from the front of the lens being accidentally knocked or scraped. A 77mm front element that doesn’t rotate it means that readily available filters can easily be used such as circular polarisers and neutral density.
EOS R5:
Image Sensor
Type 36 x 24 mm CMOS
Effective Pixels Approx. 45 megapixels
Total Pixels Approx. 47.1 megapixels
Aspect Ratio 3:2
Low-Pass Filter Built-in/Fixed
Sensor Cleaning EOS integrated cleaning system
Colour Filter Type Primary Colour
Sensor Shift-IS Yes, up to 8-Stops when used with compatible lenses 1
Image Processor
Type DIGIC X
Lens
Lens Mount RF
EF and EF-S lenses can be attached using Mount Adapter EF-EOS R
Control Ring Mount Adapter EF-EOS R, Drop-In Filter Mount Adapter EF-EOS R
(including CN-E18-80mm T4.4 L IS KAS S and CN-E70-200mm T4.4 L IS KAS S EF cinema lenses)
EF-M lenses are not compatible
Focal Length Equivalent to 1.0x the focal length of the lens with RF and EF lenses 1.6x with EF-S
Focusing
Type Dual Pixel CMOS AF II
AF System / Points 100% horizontal and 100% vertical with Face + Tracking and Auto Selection modes 100% horizontal and 90% vertical with manual selection and large zone modes 2
AF Working Range EV -6 – 20 (at 23°C & ISO100) 3
AF Modes One Shot Servo AF AI Focus AF (in A+ Scene Intelligent Auto mode )
AF Point Selection Automatic selection: Face + tracking. 1053 Available AF areas when automatically selected Manual selection: 1-point AF (AF frame size can be changed) 5940 (stills)/ (4500) movie AF positions available Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding points Manual selection: Zone AF (all AF points divided into 9 focusing zones) Manual selection: Large Zone AF (Vertical) Manual selection: Large Zone AF (Horizontal)
AF Tracking Humans, Animals (Dogs, Cats and Birds) or Vehicles (Racing cars or Motor bikes)
AF Lock Locked when shutter button is pressed halfway or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo
AF Assist Beam Emitted by built in LED or optional dedicated Speedlite (flash)
Manual Focus Selected on lens
Exposure Control
Metering Modes Real-time with image sensor, 384-zone metering. (1) Evaluative metering (linked to All AF points) (2) Partial metering (approx.
6.1% of viewfinder at centre) (3) Spot metering: Centre spot metering (approx. 3.1% viewfinder at centre) AF point-linked spot metering not provided (4) Centre weighted average metering
Metering Brightness Range EV -3 – 20 (at 23°C, ISO100, with evaluative metering)
AE Lock Auto: AE lock takes effect when focus is achieved Manual: By AE lock button in P, Av, Fv, Tv and M modes
Exposure Compensation `+/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB)
AEB +/-3 EV in 1/3 or 1/2 stop increments
Anti-flicker Shooting Yes. Flicker detected at a frequency of 100 Hz or 120 Hz. Maximum continuous shooting speed may decrease
ISO Sensitivity Auto 100-51,200 (in 1/3-stop or 1 stop increments) ISO can be expanded to L:50, H:102,400 4
Shutter
Type Electronically-controlled focal-plane shutter and Electronic shutter function on sensor
Speed 30-1/8000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
Shutter Release Soft touch electromagnetic release
White Balance
Type Auto white balance with the imaging sensor
Settings AWB (Ambience priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/Green +/-9
Custom White Balance Yes, 1 setting can be registered – From image or Live View
WB Bracketing `+/-3 levels in single level increments 3, 2, 5 or 7 bracketed images per shutter release Selectable Blue/Amber bias or Magenta/Green bias
Viewfinder
Type 0.5-inch OLED colour EVF
Dot Count 5.76 Million dots (1600×1200)
Coverage (Vertical/Horizontal) Approx. 100%
Magnification Approx. 0.76x 5
Eyepoint Approx. 23mm (from eyepiece lens centre)
Dioptre Correction -4 to +2 m-1 (dioptre)
Display Performance Power saving: 59.94 fps Smooth 119.98 fps , supress low frame rate 60 -119.8fps6
Viewfinder Information Shutter speed, Aperture, ISO speed, AF point information, Exposure level indicator, Number of remaining exposures, Exposure compensation, Battery level, Electronic shutter, HDR shooting, Highlight tone priority, Multiple-exposure shooting, Dual Pixel RAW shooting, Self-timer shooting mode, Maximum burst, AF method, Exposure simulation, Drive mode, AEB, Metering mode, FEB, Anti-flicker shooting, Still/video cropping, Shooting mode, Aspect ratio, Scene icons Auto Lighting Optimizer, AE lock Picture Style, Flash-ready, White balance, FE lock, Image Quality, High-speed sync, Bluetooth function, Wi-Fi on/off, , Histogram, Electronic level, Focus distance scale in manual focus, IS system, Audio Level – Manual (video), recording time remaining (video), headphone level (video), Video recording resolution frame rate and compression (video) Rec indicator (video)
Depth of Field Preview Yes, via customised button
Eyepiece Shutter N/A
LCD Monitor
Type 8.01cm (3.15″) Clear View LCD II, approx. 2.1million dots
Coverage Approx. 100%
Viewing Angle (Horizontally/Vertically) Approx. 170° vertically and horizontally
Coating Anti-smudge. Reinforced glass incorporated
Brightness Adjustment Manual: Adjustable to one of seven levels Colour Tone Adjustment: 4 settings
Touch Screen Operations Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting.
Display Options (1) Basic Camera settings
(2) Advance Camera settings
(3) Camera settings plus histogram and dual level display
(4) No info
(5) Quick Control Screen
(6) Off
Flash
Modes E-TTL II Auto Flash, Metered Manual
X-Sync 1/200sec mechanical shutter / 1/250th electronic 1st curtain
Flash Exposure Compensation +/- 3EV in 1/3 or 1/2 stop increments with EX series Speedlite flashes
Flash Exposure Bracketing Yes, with compatible External Flash
Flash Exposure Lock Yes
Second Curtain Synchronisation Yes via Speedlite
HotShoe / PC Terminal Yes/Yes
External Flash Compatibility E-TTL II with EX series Speedlite, wireless multi- flash support
External Flash Control via camera menu screen
Shooting
Modes Stills; Scene Intelligent Auto, Flexible priority AE, Program AE, Shutter priority AE, Aperture priority AE, Manual, Bulb and Custom (x3)
Movie: Scene Intelligent Auto, Program AE, Shutter priority AE, Aperture priority AE, Manual, Bulb and Custom (x3)
Picture Styles Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)
Colour Space sRGB and Adobe RGB
Image Processing Dual Pixel RAW – Portrait Relighting, Background Clarity ( in camera) Highlight Tone Priority (2 settings) Auto Lighting Optimizer (4 settings) Long exposure noise reduction Clarity High ISO speed noise reduction (4 settings) (stills and video) Lens optical correction – Peripheral illumination correction, Chromatic aberration correction Distortion correction (during/after still photo shooting, during video only) – Diffraction correction, Digital Lens Optimizer (during/after still photo shooting) Resize to M, S1, S2 Cropping of images (JPEG/HEIF) – Aspect ratios 3:2, 4:3, 16:9, 1:1 – Switch between vertical and horizontal cropping orientation – Image straightening – Cropping frame can be moved using touch screen operation RAW image processing Multiple exposure HDR HEIF to Jpeg conversion
Drive Modes Single, Continuous High+, Continuous High, Continuous Low, Self timer (2s+remote, 10s+remote)
Continuous Shooting Max. ApMax. Approx. 12fps. with Mechanical shutter or 20fps with electronic shutter speed maintained for 350 JPEG or 180 RAW images 78
Interval Timer Built in
File Type
Still Image Type JPEG: 2 compression options RAW: RAW, C-RAW 14 bit (14-bit with Mechanical shutter and Electronic 1st Curtain, 13-bit A/D conversion with H+ mode, 12-bit A/D conversion with Electronic shutter, Canon original RAW 3rd edition) HEIF: 10bit HEIF is available in HDR shooting with [HDR PQ] set to [Enable] Complies with Exif 2.31 and Design rule for Camera File system 2.0 Complies with Digital Print Order Format [DPOF] Version 1.1
RAW+JPEG Simultaneous Recording Yes, any combination of RAW + JPEG or RAW + HEIF possible, including Dual Pixel RAW +JPEG/HEIF
Image Size JPEG / HEIF
3:2 ratio (L, RAW, C-RAW) 8192×5464, (M1) 5808×3872, (S1) 4176×2784, (S2) 2400×1600
1.6x (crop) (L) 5088×3392, (S2) 2400×1600
4:3 ratio (L) 7280×5464, (M1) 5152×3872, (S1) 3712×2784, (S2) 2112×1600
16:9 ratio (L) 8192×4608, (M1) 5808×3264, (S1) 4176×2344, (S2) 2400×1344
1:1 ratio (L) 5456×5456, (M1) 3872×3872, (S1) 2784×2784, (S2) 1600×1600
Folders New folders can be manually created, named and selected
File Numbering (1) Consecutive numbering (2) Auto reset (3) Manual reset
File Naming 2 User presets
EOS Movie
Movie Type MP4 Video: 8K DCI/ UHD (17:9 / 16:9) 4K DCI/ UHD (17:9 / 16:9), Full HD
8K/4K/ Full HD: AVC/H.265 variable (average) bit rate, Audio: Linear PCM / AAC
4K/ Full HD: MPEG4 AVC/H.264 variable (average) bit rate, Audio: Linear PCM / AAC
8K RAW: 12bit CRM Audio: Linear PCM / AAC
Movie Size 8K DCI (17:9) 8192 x 4320 (29.97, 25, 24, 23.98 fps) RAW, intra or inter frame
8K UHD (16:9) 7680 x 4320 (29.97, 25, 23.98 fps) intra or inter frame
4K DCI (17:9) 4096 x 2160 (119.9, 100, 59.94, 50, 29.97, 25, 24, 23.98 fps) intra or inter frame
4K UHD (16:9) 3840 x 2160 (119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) intra or inter frame
Full HD (16:9) 1920 x 1080 (119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) intra or inter frame 9 10
Colour Sampling (Internal Recording) 8K/ 4K/ Full HD – YCbCr4:2:0 8-bit or YCbCr4:2:2 10bit
Canon Log Yes, Canon Log 1 , Canon Log 3 11
Movie Length Max duration 29min 59sec. (excluding High Frame Rate movies). No 4GB file limit with exFAT formatted SD card. 12
High Frame Rate Movie MOV Video: 4K – DCI 4096×2160 or UHD 3840×2160 UHD at 100fps or 119.9fps
Recorded as 1/4-speed slow motion movie
Single scene maximum recording up to 7min 29sec. 13
Frame Grab 35.4-megapixel JPEG still image frame grab from 8K DCI movie possible
33.2-megapixel JPEG still image frame grab from 8K UHD movie possible
8.8-megapixel JPEG still image frame grab from 4K DCI movie possible
8.3-megapixel JPEG still image frame grab from 4K UHD movie possible
Bitrate / Mbps CRM:
8k Raw (29.97p/25.00p/24.00p/23.98p): Approx. 2600 Mbps
8k Raw (Light) (29.97p/25.00p): Approx. 1700 Mbps
8k Raw (Light) (24.00p/23.98p): Approx. 1350 Mbps
MOV: MP4 H.264 Canon Log off
8K (29.97p/25.00p/24.00p*/23.98p) ALL-I: Approx. 1300 Mbps
8K (29.97p/25.00p/24.00p*/23.98p) IPB: Approx. 470 Mbps
8K (29.97p/25.00p/24.00p*/23.98p) IPB (Light): Approx. 230 Mbps
4K (119.9p / 100p) ALL-I: Approx. 1880 Mbps
4K (59.94p/50.00p) ALL-I: Approx. 940 Mbps
4K (59.94p/50.00p) IPB: Approx. 230 Mbps
4K (59.94p/50.00p) IPB (Light): Approx. 120 Mbps
4K (29.97p/25.00p/24.00p/23.98p) ALL-I: Approx. 470 Mbps
4K (29.97p/25.00p/24.00p/23.98p) IPB: Approx. 120 Mbps
4K (29.97p/25.00p/24.00p/23.98p) IPB (Light): Approx. 60 Mbps
Full HD (119.9p/100p) ALL-I: Approx. 360 Mbps
Full HD (59.94p/50.00p) ALL-I: Approx. 180 Mbps
Full HD ( 59.94p/50.00p) IPB : Approx. 60 Mbps
Full HD ( 59.94p/50.00p) IPB (Light): Approx.35 Mbps
Full HD (29.97p/25.00p/24.00p/23.98p) ALL-I: Approx. 90 Mbps
Full HD (29.97p/25.00p/24.00p/23.98p) IPB: Approx. 30 Mbps
Full HD (29.97p/25.00p) IPB (Light) : Approx. 12 Mbps
8K Time Lapse (29.97p/25.00p) ALL-I: Approx. 1300 Mbps
4K Time Lapse (29.97p/25.00p)ALL-I : Approx. 470 Mbps
Full HD Time Lapse (29.97p/25.00p) ALL-I: Approx. 90 Mbps
MOV: MP4 H.265 Canon Log on
8K (29.97p/25.00p/24.00p*/23.98p) ALL-I: Approx. 1300 Mbps
8K (29.97p/25.00p/24.00p*/23.98p) IPB: Approx. 680 Mbps
8K (29.97p/25.00p/24.00p*/23.98p) IPB (Light): Approx.340 Mbps
4K (119.9p / 100p) ALL-I : Approx. 1880 Mbps
4K (59.94p/50.00p) ALL-I : Approx. 1000 Mbps
4K (59.94p/50.00p) IPB: Approx. 340 Mbps
4K (59.94p/50.00p) IPB (Light): Approx. 170 Mbps
4K (29.97p/25.00p/24.00p/23.98p) ALL-I: Approx. 470 Mbps
4K (29.97p/25.00p/24.00p/23.98p) IPB: Approx. 170 Mbps
4K (29.97p/25.00p/24.00p/23.98p) IPB (Light): Approx. 85 Mbps
Full HD (119.9p/100p) ALL-I: Approx. 470 Mbps
Full HD (59.94p/50.00p) ALL-I: Approx. 230 Mbps
Full HD (59.94p/50.00p) IPB: Approx. 90 Mbps
Full HD (59.94p/50.00p) IPB (Light): Approx. 50 Mbps
Full HD (29.97p/25.00p/24.00p/23.98p) ALL-I: Approx. 135 Mbps
Full HD (29.97p/25.00p/24.00p/23.98p) IPB: Approx. 45 Mbps
Full HD (29.97p/25.00p) IPB (Light): Approx. 28 Mbps
8K Time Lapse (29.97p/25.00p) ALL-I: Approx. 1300 Mbps
4K Time Lapse (29.97p/25.00p) ALL-I : Approx. 470 Mbps
Full HD Time Lapse (29.97p/25.00p) ALL-I: Approx. 135 Mbps14
Dual Card Recording Yes (8k RAW or ALL-I and 4K at 120/100 /60/50p ALL-I recording to both cards is not possible)
Microphone Built-in mono microphone (48 Khz, 16-bit x 2 channels)
HDMI Display Output to external monitor only (output of images and shooting information, images are recorded to the card) Camera screen and External Monitor output ( Simultaneous recording to camera and external recorder, camera screen shows images with shooting information)
HDMI Output 8K or cropped 5k ProRes RAW recording via HDMI 15
4K (DCI) 59.94p / 50.00p/29.97p /25.00p/24.00p/ 23.98p, 4K (UHD) 59.94p / 50.00p/ 29.97p / 25.00p / 23.98p, Full HD 59.94p / 59.94i, 50.00p / 50.00i 480p 59.94p 576p 50p Uncompressed YCbCr 4:2:2, 8-bit or 10-bit, sound output via HDMI is also possible
Focusing Dual Pixel CMOS AF with Eye/Face Detection and Animal Tracking AF, Movie Servo AF Manual Focus (Peaking and Focus Guide available)
ISO Auto: 100-6400, H: 51200 Manual: 100-25600, H1: 51200
Other Features
Custom Functions 23 Custom Functions
Metadata Tag User copyright information (can be set in camera) Image rating (0-5 stars) IPTC data (registered with EOS Utility or Moblie File Transfer) Image transfer with caption (Caption registered with EOS Utility)
LCD Panel / Illumination Yes/Yes
Water/Dust Resistance Yes 16
Voice Memo Yes
Intelligent Orientation Sensor Yes
Playback Zoom 1.5x – 10x in 15 steps
Display Formats (1) Single image (2) Single image with information (2 levels) Basic – Shooting information (shutter speed, aperture, ISO and Image quality) Detailed – Shooting information (shutter speed, aperture, ISO, metering Image, quality and file size), Lens information, Brightness and RGB histogram, White balance, Picture Style, Color space and noise reduction, Lens optical correction, GPS information, IPTC information (3) 4 image index (4) 9 image index (5) 36 image index (6) 100 image index (7) Jump Display (1, 10 or 100 images, Date, Folder, Movies, Stills, Protected images, Rating) (8) Movie edit (9) RAW processing (10) Rating
SlideShow Image selection: All images, by Date, by Folder, Movies, Stills, Protected images or Rating Playback time: 1/2/3/5/10 or 20 seconds
Repeat: On/Off
Histogram Brightness: Yes RGB: Yes
Highlight Alert Yes
Image Erase Single image, select range, Selected images, Folder, Card
Image Erase Protection Erase protection of Single image, Folder or Card all found images (only during image search)
Self Timer 2 or 10 sec.
Menu Categories (1) Shooting menu (2) AF Menu (3) Playback menu (4) Network (5) Setup menu (6) Custom Functions menu (7) My Menu
Menu Languages 29 Languages English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Indonesia and Japanese
Firmware Update Update possible by the user (Camera, Lens, External Speedlite, BLE remote control, Lens adapter)
Interface
Computer SuperSpeed USB 3.1 Gen 2 USB C connector
Wi-Fi Wireless LAN (IEEE802.11a/b/g/n/ac) (5Ghz /2.4 GHz) 17, with Bluetooth 5 support, Features supported – EOS Utility, Smartphone, Upload to image.canon, Wireless printing
Other HDMI micro out (Type D), External Microphone In/Line In (Stereo mini jack), Headphone socket (Stereo mini jack), N3-type terminal (remote control terminal) Flash sync socket
Direct Print
PictBridge Not supported
Storage
Type 1x CFexpress type B, 1x SD/SDHC/SDXC and UHS-II
Supported Operating System
PC Windows 8.1 and Windows 10 (tablet mode not supported)
Macintosh OS X v10.12, 10.13, 10.14,10.15, 11
Software
Image Processing Digital Photo Professional 4.14. or later, Digital Photo Professional Express mobile app ( iOS only) (RAW Image Processing not DUAL PIXEL RAW on DPP Express mobile)
Other EOS Utility 3.12.3 or later (incl. Remote Capture), Picture Style Editor, WFT Utility, EOS Lens Registration Tool, EOS Web Service Registration Tool, Canon Camera Connect app and image.canon app (iOS/Android) Mobile File Transfer (iOS/Android)
Power Source
Batteries Rechargeable Li-ion Battery LP-E6NH (supplied)/LP-E6N
Battery Life With LCD Approx. 490 shots (at 23°C)
With LCD Approx. 470 (at 0°C)
With Viewfinder Approx. 320 shots (at 23°C)
With Viewfinder Approx. 310 (at 0°C)18
Battery Indicator 6 levels + percentage
Power Saving Power turns off after 30 seconds, 1, 3, 5, 10 or 30mins
Power Supply & Battery Chargers Battery charger LC-E6E (supplied), AC Adapter AC-E6N and DC Coupler DR-E6, AC Adapter Kit ACK-E6N/ACK-E6, Car Battery Charger CBC-E6, PD-E1 USB power adapter
Accessories
Wireless File Transmitter Wireless File Transmitter WFT-R10B
Lenses All RF lenses (EF & EF-S via Lens adapters)
Lens Adapters Mount Adapter EF-EOS R Control Ring Mount Adapter EF-EOS R Drop-In Filter Mount Adapter EF-EOS R
Flash Canon Speedlite (EL-1, EL-100, 90EX, 220EX, 270EX, 270EX II, 320EX, 380EX, 420EX, 430EX, 430EX II, 430EX III-RT, 470EX-AI, 550EX, 580EX, 580EX II, 600EX, 600EX-RT, 600EX II-RT, Macro-Ring-Lite MR-14EX, Macro Ring Lite MR-14EX II, Macro Twin Lite MT-24EX, Macro Twin Lite MT-26EX Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)
Remote Controller / Switch Remote control with N3 type socket, Wireless Remote Control BR-E1, Infrared Remote RC-6 and Speedlite 600EX-II-RT
Other BG-R10 battery grip, GP-E2 GPS receiver (digital compass not supported), Stereo Microphone DM-E1 / DM-E100
Physical Specifications
Body Materials Magnesium Alloy body and Chassis with some components consisting of polycarbonate with glass fibre
Operating Environment 1 – 40 °C, 85% or less humidity
Dimensions (W x H x D) 138.5 x 97.5 x 88mm
Weight (Body Only) Approx. 650 g (738 g with card and battery)
Notes 1. 8-stops based on the CIPA standard with RF 24-105mm F4 L IS USM at a focal length of 105mm
2. The AF area available vary depending on the lens used
3. The lowest light AF is available with an f/1.2 lens, center AF point, One-Shot AF, at 23°C / 73°F, ISO 100) Except RF lenses with a Defocus Smoothing (DS) coating
4. Recommended Exposure Index
5. with 50mm lens at infinity, -1m-1 dpt
6. Low light AF performance will be reduced when supress low frames is used
7. Max Frames per second will vary depending on the battery type, if Wi-Fi is turned on, operating temperature lens used and file size. The number of possible shots and maximum burst vary depending on shooting conditions (including [1.6x (crop)], aspect ratio, subject, memory card brand, ISO speed, Picture Style, and Custom Function). The speeds quoted are based on testing with the following settings: Shutter speed 1/1000 sec. or faster, Aperture Maximum aperture, Flash Not used, Flicker reduction Not used, Battery pack Fully charged LP-6NH, Temperature Room temperature (23°C / 73°F). Battery grip or WFT-R10 Not used, Wi-Fi settings OFF,
8. Max Frame rates for stills can vary between lenses and aperture setting used
9. If the cameras internal temperature becomes too high the maximum recording time will be reduced
10. With Firmware v1.30
11. With Firmware v1.30
12. If the cameras internal temperature becomes too high the maximum recording time will be reduced
13. In High frame Rate Movie mode sound is not recorded
14. With Firmware v1.30
15. 8k and cropped 5k ProRes RAW with Atomos Ninja V+ or cropped 5k ProRes RAW with Atomos Ninja V
16. Although the camera features dust- and water-resistant construction, this cannot completely prevent dust or water droplets from entering the camera.
17. Wi-Fi use may be restricted in certain countries or regions
18. Based on the CIPA Standard and using the battery supplied with the camera, except where indicated. In power saving mode
RF24-105mm F4L IS USM:
Image Size Full Frame
Angle of view (horzntl, vertl, diagnl) 74° – 19°20′,
53° – 13°,
84° – 23°20′
Lens construction (elements/groups) 18/14
No. of diaphragm blades 9
Maximum Aperture f/4
Minimum aperture 22
Closest focusing distance (m) 0.45
Maximum magnification (x) 0.24
Distance Information Yes
Image stabilizer 5 stops
AF actuator Nano USM
Accessories
Lens cap E-77 II
Lens hood EW-83N
Lens case/pouch LP1319
Rear End Cap Lens Dust Cap RF
Magnification with Extension Tube EF12 II Not Compatible
Magnification with Extension Tube EF25 II Not Compatible
Extender Compatibility Not Compatible
Resolution & speed – no compromise
Stay sharp, stay focused
Power for professionals
Revolutionising videography. Again.
Send images quickly and easily
45 Megapixel full-frame CMOS sensor
Extraordinary detail with up to 51,200 ISO
20 Frames Per Sec Electronic Shutter
8 stop IS
In-body Image Stabiliser
Optical Image Stabiliser
Full Frame 8K Video at 30 FPS
High Frame Rate 4K Movies at up to 120fps
Wi-Fi and Bluetooth for wireless connectivity
A new era in image quality
New standards in high resolution stills, and phenomenal 8K video quality to match. The EOS R5 advances image quality to a whole new level for stills and movies with a blistering 20fps electronic shutter or 12fps mechanically. The EOS R5 is accomplished, refined and built for magnificence.
Be the filmmaker
Commit your best work to stunning 8K video and relish the prospect of exciting new possibilities for creative capture. At such a high resolution, EOS R5 allows you to fully expand the genre of filmmaking and explore dynamic new ways of telling your story.
New standards in stability
For the first time on any Canon camera, In Body Image Stabilisation is offered which works in harmony with Canon RF lenses with IS to provide the ultimate in shake-free super-sharp images and movies. Film or shoot without a tripod in the knowledge that you’ll always achieve the smoothest, sharpest result.
Cloud connected. And then some
Shoot and transfer images and video on the move thanks to built-in Wi-Fi which can link to Canon’s brand new image.canon service. Compatible with Auto Image Transfer, EOS R5 allows you to shoot and edit on the move or download automatically to your home computer.
Versatile and adaptable
For performance that matters, look under the skin. Dual Card Slots means much longer shooting time. And as the EOS R5 is part of the incredible EOS R family, with the stunning RF mount that offers the ultimate in quality and adaptability, it’s also compatible with Canon’s incredible EF lens range thanks to a choice of RF-EF adapters for seamless integration.
Resolution & speed – no compromise
Nothing else comes close. Capture incredibly detailed 45 megapixel images at up to 20fps in complete silence with full AE and AF tracking.*
Stay sharp, stay focused
Moving subjects are tracked with ease, thanks to a deep-learning, 1053-area AF system that tracks heads, faces and eyes and works on dogs, cats and birds too.
Power for professionals
New levels of performance drive your creativity to new heights. Like an Image Stabilizer that’s effective up to 8 stops, for handheld photography at slow shutter speeds.‡
Revolutionising videography. Again.
The EOS R5 can capture stunning 8K DCI RAW 24/25/30p video internally to its CFexpress card and 4K video at frame rates up to 120p – all with continuous focusing.
Send images quickly and easily
Get ahead and start your digital workflow on the move. Built-in Wi-Fi lets you transfer images to smart devices, to cloud accounts using image.canon, and clients via FTP/FTPS.
* Shooting speed may vary depending on the battery type, the use of a battery grip or Wi-Fi, and operating temperature. For further details see specifications.
† Centre point, when used with f/1.2 lenses, One-shot mode.
‡ According to CIPA standards (with compatible RF lenses)
§ According to CIPA standards at 23˚C using the LCD in power-saving mode.
® * Equipped with Bluetooth® low energy technology. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Canon Europe Ltd. is under license. Other trademarks and trade names are those of their respective owners.
RF24-105mm F4L IS USM Lens:
A general purpose, practical, professional zoom for every day photography and filmmaking
Steady, handheld professional performance with 5-stops of image stabilisation
Fast, smooth, quiet Nano USM focusing brining ideal attributes for photos and video
Legendary L-series image quality for outstanding detail, depth and sharpness
Smart, professional design, built to accompany you everywhere, every day
Powerful image stabilisation for new ways of shooting
The EOS R5 features a five-axis in-body Image Stabilizer, which provides up to 5 stops of protection against camera shake when shooting with lenses that don’t have their own IS. However, when a compatible IS-equipped RF lens is fitted the two stabilisation systems work together creating an Intelligent Image stabilization system that delivers an incredible 8-stop advantage.
New levels of realism from an electronic viewfinder
The EOS R5’s electronic viewfinder refreshes at 120 frames per second and features no fewer than 5.76 million dots. The result is a staggering realistic view of the world that will have you feeling totally immersed in the scene – as if there is nothing between you and your subject. Of course, this state-of-the-art EVF also previews factors such as white balance, depth of field and Picture Style, so you’ll always know what you are shooting.
AF and subject tracking powered by deep-learning AI
The EOS ITR AF X autofocus system in the EOS R5 has been programmed using a deep-learning AI, originally developed for our ground-breaking EOS-1D X Mark III DSLR camera. In Face/Eye detection mode, the system recognises faces accurately, including those in profile when only one eye is visible. This ensures subjects are kept razor sharp, even when moving unpredictably and depth of field is shallow. And if a person turns away for a moment, their head continues to be tracked so that their face is sharp when they turn back towards the camera.
Furthermore, the EOS R5’s deep-learning AI has been programmed with the ability to recognise and track cats, dogs and birds – focusing on either their bodies, faces or eyes. This makes photographing wildlife easier than ever before, especially subjects such as birds in flight.
This class-leading AF system can focus in as little as 0.05sec and in light levels as low as -6EV† giving you the confidence you need to capture superb results.
More powerful battery
The EOS R5 is powered by a more powerful new LP-E6NH battery, which adds 20 per cent more capacity than older LP-E6N batteries, letting you capture (on average) 490 shots on a single charge.§
LP-E6NH batteries can be charged using the supplied battery charger or in-camera via USB C 3.1, with 5V/1.5A power delivery (PD) capabilities. The BG-R10 battery grip is also available, which can accommodate two batteries at once for extended shooting times.
Older LP-E6 and LP-E6N batteries are compatible with the EOS R5, although the very fastest shooting rates and in-camera charging are not available when using the LP-E6.
Shoot RAW video at 8K resolution
Capture superb 8K 12-bit RAW video using the full width of the EOS R5’s full-frame sensor for a truly cinematic result, with footage being captured internally to a CFexpress card. 8K filming is possible with continuous AF with eye and face tracking – perfect for run-and-gun style documentary filming.
RAW 8K footage gives the best image quality on the EOS R5, but 8K can be captured in other ways too, which speed up the editing workflow – choose between 10-bit 4:2:2 MP4/H.265 or 8-bit 4:2:0 MP4/H.265 codecs.
Alongside its ground-breaking 8K capabilities, the EOS R5 sets new standards for videographers shooting in 4K. Capture 4K DCI (full frame) and 4K UHD at frame rates up to 120p (119.88fps) with 4:2:2/10-bit quality, enabling silky smooth slow-motion with stunning high resolution. At frame rates up to 59.94fps, there is a choice between using the full width of the camera’s sensor or a 1.6x crop, which is similar in size to Super 35mm.
For those needing the very highest 4K quality, the EOS R5’s 4K HQ mode reproduces stunning detail at frame rates up to 30p by oversampling 8K footage. The results need to be seen to be believed.
Reviews
There are no reviews yet.
